| US$4,000.00-9,000.00 | 1 Piece (MOQ) |
| Model | UNIT | Z3040x11-1 | Z3040x14-1 |
| Max.drilling dia. | mm | 40 cast iron/ steel | 40 cast iron/ steel |
| Distance between spindle axis and column surface | mm | 350-1030 | 320-1370 |
| Headspindle level travel distance | mm | 670 | 1000 |
| Distance from spindle nose to table surface | mm | 170-1110 | 280-1210 |
| The rock lift height | mm | 680 | 680 |
| The rock up and down speed | Mm/m | 1.32 | 1.32 |
| Rock rotary angle | Degree | ±90 | ±90 |
| Spindle Cone | MT | 4 | 4 |
| Spindle travel | mm | 260 | 260 |
| Spindle speed step | 12 | 12 | |
| Spindle speeds range | r/min | 40-1896 | 40-1896 |
| Spindle feeding step | 4 | 4 | |
| Spindle feeding range | mm/r | 0.13-0.54 | 0.13-0.54 |
| Max.torque of spindle | N | 200 | 200 |
| Max. Resistance of the spindle | N | 10000 | 10000 |
| Main motor power | kw | 3 | 3 |
| N.W./G.W. | kg | 1500/1600 | 1900/2200 |
| Overall dimensions(L×W×H) | cm | 170x705x220 | 205x820x24 |
