| US$5,000.00-8,000.00 | 1 Piece (MOQ) |
| Detailed Parameters | ||||
| Total Power | 14.5kw | |||
| Booth Outside | 7050*5200*3600 Length*Width*Height (mm) | |||
| Booth Inside | 6900*3900*2750 Length*Width*Height (mm) | |||
| Door Dimension | 3 folds main door,3,000×2,700mm(W×H),Equipped with Handle & Lock one personal door,800×2,000mm(W×H),Equipped with Handle & Lock | |||
| Walls Panel | 75mm thick,EPS panel, covered by 0.426mm color steel. Tongue and groove interlock structure | |||
| Basement System | Grid Plates (Galvanized)* 2rows Diamond Plates (Powder Coated or Galvanized)* 3rows 2 ramps,each size 800x2,000mm(WxL) | |||
| Heating System | Diesel Burner*1unit (Italy RIELLO, G20) stainless Heating Exchanger*1unit Heating Cabinet*1unit,rock-wool insulation | |||
| Filter System | Primary Filter* 1set, G3 Grade(EU-3) Air-Intake Filter* 1set,F5 Grade(EU-5) Air-Exhaust Filter*G3 Grade(EU-3) | |||
| Air System | Air-Intake Fans* 2units, Centrifugal Fans with 4 KW motor each Air-Exhaust Fan* 1unit, Centrifugal Fans with 5.5 KW motor Cabinet for the fans* 1unit, Air Ducts and Belimo NMU230 20NM electric damper | |||
| Illumination | Ceiling Lights * 32pcs, 20w LED lamp, Side Lights * 32pcs,20w LED lamp with Light Fixtures, anti-explosion design,Illumination ≥800LUX | |||
| Control System | *1unit,Button type control box, with safety protection button | |||
