UL Split Core Monitoring CT Current Transformer 5A/2.5mA Open Type

Product Details

Product Description

Product Description
Xh-Sct-T24
Product Description
Split-Core AC Current Transformer current Sensor XH- SCT-T10(B)
φ10mm Opening With 5 To 80 Amp Rating
Description:
Jiangyin Spark XH-SCT-T10 Series split-core current senses AC current from 5 to 80 Amps passing through the center conductor.Split core CTs are designed for fast and easy installation.The split core design permits non-contact current measurements through magnetic field induction without requiring that the primary wire be taken offline and disconnected for CT installation.This method permits a safer,easy and portable current measurement.

SPECIFICATIONS : 1,Rated Voltage:0.66KV 2,Insulation Voltage:3500V 3,Rated Frequency:50HZ/60HZ 4,Operating Temperature:-20ºCto 70ºC 5,Weight:70g 6,Certificates:UL ,CE ,ROHS

FEATURES: 1,Small cost 2,Split core design ,Easier installation 3 Build diode ,no high voltage danager 4,Good linearity at very low current

Model	Input(A)	Max currnet(A)	Output
XH-SCT-T10A	0.2-80AAC	100AAC	mA/0.333VAC /0-3VAC
XH-SCT-T10B
