Tissue Making Toilet Reel/ Paper Roll Making Machine/ Rewinder

Product Description

Tissue Making Toilet Reel/ Paper Roll Making Machine/ Rewinder
PRODUCTION DESCRIPTION
Specifications
1 .Paper grades: toilet paper, facial tissue, paper napkin
2. Grammage: 13-30gsm
3. Working speed:0-180m/min

Model	1575	1760	1880	2500	2800
Raw paper width	1750mm	2000mm	2100mm	2400mm	2750mm
Raw paper diameter	Φ1100mm (other specification can be appointed)
Raw paper core diameter	Φ76.2mm (other specification can be appointed)
Finished outer diameter	90-350 mm
Finished core diameter	Φ76.2mm (other specification can be appointed)
Parameter setting	HMI
Programming control	PLC
Embossing	single embossing, double embossing, steel to steel embossing(to be ordered)
Embossing bottom roller	felt roller, woolen roller, rubber roller, steel roller(to be ordered)
Production speed	0-180 m/min
Perforating	4 pieces of anvil blades
Perforating size	110-145mm
Power	4KW-22KW
Unreeling	1-3 layers

F&Q Q.:Are you a factory or trading company?A.: We are a factory and manufacturer.Q.:How does your factory do regarding quality control?A.:We pay much attention on quality controlling from very beginning to the very end. Fully check and test takes before shipment.Q.:Where is your factory located? How can I visit there?A.:Our factory located at Shandong, China.You can fly to QINGDAO international airport directly. We will arrange to pick you up.Q.:What's service or guarantee can you offer?A.: One year guarantee for key parts of machine, Machine installing and worker training service, free technical support whole life.

---
