| Size(L×W×H) | 9570×2800×2970 mm | ||
| Outline dimension | A)Wheel-base | 3465mm | |
| B)Crawler length | 4260mm | ||
| C)Ground clearance of platform | 1060mm | ||
| D)Tail slewing radius of platform | 2750mm | ||
| E)Width of upper body | 2710mm | ||
| F)Gauge | 2200mm | ||
| G)Chassis width | 2800mm | ||
| H)Track width | 600mm | ||
| I)Chassis ground clearance | 478mm | ||
| J)Cab roof height | 2970mm | ||
| K)Transport boom height | 2945mm | ||
| L)Transport length | 9570mm | ||
| Operating range | a)Max.digging height | 9750mm | |
| b)Max.dumping height | 6980mm | ||
| c)Max.digging depth | 6750mm | ||
| d)Max. vertical digging depth | 5900mm | ||
| e)Max.digging radius | 9940mm | ||
| f)Max.digging reach at ground level | 9775mm | ||
| Performance parameters | Operating weight(steel track) | 21.8t | |
| Standard bucket capacity | 1.0m3 | ||
| Bucket digging force | 155kN | ||
| Bucket rod digging force | 110kN | ||
| Travel speed(Max./Min.) | 5.2/3.3 km/h | ||
| Ground pressure | 46kPa | ||
| Swing speed | 11.8rpm | ||
| Engine | Brand | top brand | |
| Model | QSB6.7 | ||
| Type | Direct injection, 4-stroke, water-cooled, turbocharged, intercooled | ||
| Power | 129kW/2000rpm | ||
| Displacement | 6.7L | ||
| Oil tank capacity | Fuel tank | 385L | |
| Hydraulic tank | 290L | ||
