304 Stainless Steel Automatic Pneumatic Rising Bollards

Product Description

All in one Hydraulic rising bollard introduce
Install micro hydraulic pressure into raising bollard . Every bollard is a independent unit . Compare central hydraulic system drive.It have those advantages :
1,No need lay underground hydraulic pipeline. Easy installation. Low construction cost
2,Because of Have no hydraulic pipeline. It only need inspect independent bollard during maintenance.it is easy to take out the control box from earth .Easy repair and maintenance
System takes of micro motor and a integration ports connect gear pump and oil box . Then use a all in one hydraulic cylinder to built a complete micro hydraulic .use structure parts to install this system into roadblock inner.In this way complete electronic energy >mechanical energy>hydraulic energy conversation process .totally reach micro .electronic.;liquidize integration
Product features :
(1) Emergency release ;
(2) There is no limited on distance between Independent bollard and control system
(3)Can make sure more than one bollard synchronous raise and fall
(4)Can takes of short/remote control and short swing card or long range radio swing card control .
(5)Can connect with PC reach sequencing control.Suitable for high frequency high safety requirement place
Basic bollard parameter :
Power supply : 220V
Output power 0.22KW
Gross weight 150KG
Board materials SUS304 material
Board thickness 6mm
Anti Impact standard 15K Joule
Bollard diameter : 218mm
Bollard surface process : Polishing, Brushing,
Waterproof standard IP67
Raised height 500-600mm( Optional)
Lift force :500KG
Movement manner : Motor drive
Movement limit : Magnet induction limit .PC time control
Alarm method :30mm Two ways reflective tape ( Optional LED )
Lift time : 4-6 seconds
Board control : Line control /remote control or connect with other equipment
Control distance : Short route remote control 30-50m
Color : Silver

---
