Welcome to visit

Hydraulic Clamping Z3050 Cheap Radial Drilling Machine

US$4,600.00 1 Piece (MOQ)

Basic Info.

Model NO.
Z3050
Structure
Radial Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Number of Shaft
1
Hole Diameter
50
Automatic Grade
Manual
Precision
Precision
Certification
GS, CE, ISO 9001
Condition
New
Rocker Arm Rotation Angle
360
Horizontal Moving Distance of Spindle Bo
1250mm
Spindle Feed
0.10/0.16/0.22/0.25/0.35/0.56
Maximum Allowable Resistance of The Spin
16000n
Main Motor Power
4kw
Lifting Motor Power
1.5kw
Machine Weight
2000kg
Overall Dimensions
2170*950*2450mm
Transport Package
Export Wooden Cases
Specification
2170*950*2450
Trademark
JEPPS
Origin
Shandong, China

Packaging & Delivery

Package Size
227.00cm * 105.00cm * 255.00cm
Package Gross Weight
2010.000kg

Product Description

Product Description
Product Parameters
Main Parameters Z3050×16 Radial Drilling Machine
Maximum Drilling Diameter (mm) 48/50 (steel/casting)
Distance from spindle centerline to column generatrix (minimum - maximum) (mm) 360-1600
Distance from spindle end to base table (minimum-maximum) (mm) 300-1150
Spindle travel (mm) 220
Spindle taper MT.5
Spindle speed stages 6 Level
Spindle speed range (r/min) 78.135.240.350.590.1100

Detailed Photos
Company Profile
Certifications
Packaging & Shipping
FAQ
