Vertical Manual Milling Machine Reliable Conventional Milling Machine for Metal

Product Description

Enduring durability and exceptional cost-effectiveness make this universal model a must-have for any operation seeking reliability and affordability in their milling processes.
√ Enjoy the unbeatable combination of low prices and superior quality, ensuring exceptional value without compromising on performance.
√ Assembled in China with precision parts sourced from Taiwan, ensuring high-quality construction and reliable performance.
√ Offers an exceptional spindle tolerance of just 0.005mm, guaranteeing precision in every milling task.
√ Perfectly tailored for the processing of molds for household appliances and daily necessities, enhancing production capabilities in these sectors.
1. WORKTABLE
Discover precision at its finest with our expertly crafted worktable, featuring ultra-audio quenching, precision grinding, and meticulously scraped guides for unparalleled smoothness. Enhance versatility with an optional rotary table.
2. TURRET MILLING HEAD
Our advanced turret milling head is engineered to swivel 45° forward-backward and rotate 90° left-right, providing seamless flexibility for tackling intricate angles and complex project demands.
3. SPINDLE
Achieve unmatched precision and accuracy with our high-precision R8/NT30/NT40 spindle, offering an impressive spindle runout of a mere 0.003mm.
4. X/Y/Z AUTO FEED
Revolutionize your operations with automatic feeds on X/Y axes and the electric lifting of the Z axis, significantly enhancing efficiency and simplifying processes.
5. DRO
Maximize operational precision with our adaptable 2-axis or 3-axis DRO, tailored to meet your specific requirements and elevate performance to new heights.
Vertical Manual Milling Machine Reliable Conventional Milling Machine for Metal

Model				5EA
Table size			mm	1370*280*90
Travel		X axis	mm	1000
		Y axis	mm	385
		Z axis	mm	340
Travel of spindle quill			mm	127
Maximum distance from spindle nose to table			mm	470
Spindle	Rotation speed (Step speed milling head)	50HZ	rpm	60-4530
		60HZ	rpm	80-5440
	Rotation speed (Variable speed milling head)	50HZ	rpm	40-3125
		60HZ	rpm	50-3750
	Rotation speed (Inverter speed milling head)	50HZ	rpm	0-4200
		60HZ	rpm	0-4200
	Taper			NT40
	Rated power		HP	5HP
Tilt Angle			Forward and backward	±45°/0°
			Left and Right	±90°
Dimension			mm	1600*1800*2200
Weight			kg	1750

Shenzhen Joint Machinery Co., Ltd. is a distinguished global leader recognized for its professional manufacturing and export expertise in CNC lathe machines, CNC deep hole drilling machines, and Swiss-type automatic lathes. Our expansive portfolio encompasses a wide range of top-tier milling and grinding machines, reflecting our unwavering commitment to delivering excellence and unmatched service on an international scale. By harnessing state-of-the-art technologies from Taiwan and Germany, we ensure our production processes uphold the industry's highest standards in quality and reliability. Our machines are celebrated for their precision, stability, and reliability, adeptly addressing diverse machining challenges with ease. Our esteemed product lineup has achieved international acclaim, serving markets across Asia, Europe, South America, North America, and beyond. We remain dedicated to nurturing enduring partnerships with our clients, consistently delivering significant business value and success together.

---
