2000bph 5L Bottle Rotary Water Automatic Filling Machine

US$54,000.00-59,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

DCGF12-12-4

Type

Normal Pressure Filling

Automatic Grade

Automatic

Material Type

Liquid

Filling Valve Head

Multi-Head

Feed Cylinder Structure

Single-Room Feeding

Dosing Device

Surface Type

Filling Principle

Atmospheric Pressure

Packaging Container Lifting Structure

Chute Lifting

Structure

Rotary

Packaging

Bottle

Packaging Material

Film

Washing Heads

Filling Heads

Capping Heads

Transport Package

Wooden Case

Specification

1800-2000bph

Trademark

Origin

China

HS Code

8422303090

Production Capacity

200sets/Year

Packaging & Delivery

Package Size

310.00cm * 230.00cm * 230.00cm

Package Gross Weight

5000.000kg

Product Description

Product Description

DCGF12-12-4 is Gloy's New model for plastic 5L bottle filling .the machine use for filling water in plastic bottle from 5L to 10L .with the functions of automatic washing ,filling screw capping in one machine . And It has automatic cap loading washing online .it is rotary type 3in1 machine with high capacity 2500bph for 5L bottle . we connected automatic stick labeling machine with filling .the whole filling labeling line use high quality material SUS304,famous brand confirgation . whole line working automatically and running stable .It is the ideal equipment for a beverage factory.
Product Parameters
main parameters for 5L rotary filling machine

Washing heads	12
Filling heads	12
Capping heads	4
Speed	1200-1500bph For 5L
Power	Main motor 4kw
Washing pump	0.37kw
Filling pump	0.75kw
Dimension	About 3100x2300x2200mm
Weight about	3700kg

Detailed Photos
