Hailin Cpd25 2.5ton Electric Forklift Battery Forklift Electric Brand New
US$10,900.00
1 Piece
(MOQ)
Basic Info.
Model NO.
CPD25
Cab Location
Adjustable
Type
Electric Forklift
Power
Diesel Engine
Load Capacity
1T - 5T
Fuel
Diesel
Load center
500mm
Condition
New
Transport Package
Plastic Bag
Trademark
HAILIN
Origin
Shandong
HS Code
8427109000
Production Capacity
300
Product Description
CPD-30 Electric Forklift Truck Dynamic style: electric Rated load kg: 3000 The load center mm: 500 Hoisting height mm: 3000 Free hoisting height mm: 100 Mm: goods fork size 1070 * 125 * 45 Door frame Angle: before/after 6/12 The minimum bending radius: 2400 mm Least square stacking channel width: 4280 mm Least square channel width: 2120 mm The minimum clearance from the ground: 135 mm Protect head frame height: 2160 mm Before hanging distance: 495 mm Maximum speed: 20 km/h Maximum lifting speed: 460 mm/h The maximum traction: 20 kn Maximum gradeability: 20% Take goods fork: 2 3770 mm No goods fork: 2 2700 mm Full width: 1226 mm Pallet fork maximum lifting height (with when shelves) 4265 mm Door frame ground height: 2060 mm The front wheel: 28 x9-15-12 pr The rear wheel: 6.50-10-10 pr The wheelbase: 1700 mm Wheel tread front/rear wheel: 1000/970 mm No load weight: 4350 kg Battery voltage/capacity: 12 v / 80 ah Engine type: four d27g31 new wood Rated power: 37 kw / 2500 RPM Rated torque: 156 nm / 1700-1900 RPM Cylinder diameter X trip: 90 x105mm Number of cylinders: 4 Capacity: 2.54 L Fuel tank capacity: 70 l Working pressure: 17.5 Mpa
