| Performance | 12VDC / 24VDC |
| Single line rated pull | 12000lbs(5443kg) |
| Motor | 6.0hp / 4.5kw, series wound |
| Control | Remote switch, 12ft(3.7m) lead |
| Gear train | 3 stage planetary |
| Gear reduction ratio | 265 : 1 |
| Clutch | Sliding ring gear |
| Braking action | Automatic in-the-drum |
| Drum size | Diameter 2.52"±(64mm), length 8.82"±(224mm) |
| Cable | 88ft of 3/8"±diameter (26m of 9.5mm diameter) |
| Fairlead | 4-way roller fairlead |
| Remote control | Included |
| Battery | Recommended: 650CCA minimum for winching |
| Battery leads | 2 gauge, 72"(1.83m) |
| N.W./G.W. | 37.5kg / 38kg |
| Overall dimensions | L×W×H: 21.3"×6.3"×8.6" (552×160×218mm) |
| Mounting bolt pattern | 10.00±0.015"±×4.50±(254×114.3mm) |
| MEAS | 61×19.5×48.5cm (1pc) |
