High Precision 3-Axis Machining Center CNC Vertical Machine Center Milling Machining Center

Product Description

PRODUCT DESCRIPTION In milling - unlike metal turning - the workpiece remains stationary and the mobile cutting edges of the CNC machine move to remove the excess material. This type of machining ensures exceptional accuracy and repeatability, even when making very complex parts and components
Modern industry requires the use of increasingly complex parts that can only be obtained with the help of appropriate technologies. CNC milling is a good example of this. By incorporating computer-controlled numerical devices into the processing process, a high level of precision is achieved, resulting in high quality components and complete repeatability.
Due to the exceptional accuracy achieved by CNC machines, they are used primarily to form metal shapes. The most common is steel. It has a high degree of hardness, however that does not interfere with our machines capacity for precise machining. Stainless steel milling also includes related material groups such as austenitic or heat resistant. This range also includes structural steel, hardened steel, spring steel and many more.
A CNC milling machine can easily handle cast iron blocks (white, gray, black), aluminum and its alloys, tungsten, molybdenum or magnesium. It is also possible to mill copper, nickel super alloys or titanium, as well as various types of composites (especially thermoplastic and thermosetting plastics).

Travel (XYZ)	520 x 420 x 220 mm (20" x 16.5" x 9")	1,020 x 830 x 245 mm (40" x 33" x 10")	1,520 x 1,150 x 245 mm (60" x 45" x 10")	1,040 x 850 x 270 mm (41" x 33.5" x 11")
Spindle	2kwatt liquid chilled spindle up to 40,000 RPM	Up to 60,000 RPM	Up to 60,000 RPM	Standard 4 kwatt, 1k - 40k RPM, e-25 HSK Collet Upgrade 8 kwatt, 100 - 34k RPM, e-32 HSK Collet
Feed	Up to 28 m/min (1,102 in/min)	Up to 22 m/min (866 in/min)	Up to 22 m/min (866 in/min)	Up to 40 m/min (1,574 in/min) - X, Y Up to 28 m/min (1,102 in/min) - Z
Tool Changer	24 stations automatic tool changer	Up to 143 stations automatic tool changer	Up to 143 stations automatic tool changer	143 tool change capacity
Working Area	500 mm x 400 mm (19.5" x 16")	1,000 x 700 x 200mm (39" x 27.5" x 7.5")	1,500 x 1,000 x 200mm (59" x 39" x 7.5")	1,000 x 700 x 200mm (39" x 27.5" x 7.5")
Rotary axis	Optional 4th axis	Optional 4th axis and 5th axis	Optional 4th axis and 5th axis	Optional 4th axis and 5th axis
Footprint (W x D x H)	805 x 1,290 x 1,880 mm (32" x 51" x 74")	1,740 x 1,740 x 1,950 mm (69" x 69" x 77")	2,410 x 2,280 x 1,950 mm (95" x 90" x 77")	3,358 x 1,855 x 2,235 mm (106″ x 73″ x 88″)
Weight	approx. 700 kg (1,543 lbs.)	approx. 1,300 kg (2,866 lbs.)	approx. 2,500 kg (5,512 lbs.)	approx. 3,800 kg (8, 378 lbs.)
