| Negotiable | 1 Piece (MOQ) |
| Model | 3HE-MF750 | 3HE-MF150/1500 | 3HE-MF450/1500 | 3HE-MF300/3000 | 3HE-MF/4500 |
| Optical parameters | |||||
| Work model | Continuous modulation | ||||
| Average power | 120 | 250 | 500 | 500 | 750 |
| Average pulse | 75 | 150 | 450 | 300 | 450 |
| Max power | 750 | 1500 | 1500 | 3000 | 4500 |
| Max pulse energy | 7.5 | 15 | 0.9 | 30 | 45 |
| Wavelength | 1080nm | ||||
| Repeat rate | 0-5000Hz | 500-5000Hz | 0-5000Hz | ||
| Pulse width | 0.05-50ms | 0.05-0.6ms | 0.05-50ms | ||
| Output power stability | <2% | ||||
| Red light | configured | ||||
| Output parameters | |||||
| Output connector | QBH (customizable) | ||||
| Fiber core diameter | 25, 50, 100 optional | 50, 100, 200 optional | |||
| BBP(mm.mrad) | 0.4, 2, 5 | 2, 5, 10 | |||
| Electronic control characteristics | |||||
| Input voltage(VAC@47-63Hz) | 200-400, single-phase | 340-420, three-phase-five-wire | |||
| Control model | External RS232/External AD | ||||
| Power adjustment | 10-100 | ||||
| Power consumption | 300 | 600 | 2000 | 1200 | 1800 |
| Other characters | |||||
| Size (mm) | 450*240*680(with handle) | 650*890*100(with ring) | 650*1000*1450(with ring) | ||
| Weight (KG) | <30 | <50 | <150 | <200 | |
| Cooling | Water cooling | ||||
| Operating temperature(ºC) | 10-40 | ||||
