Factory Price Grain Cleaner Seed Wheat Pre Cleaner

Product Description

Product Description
Factory price grain cleaner seed wheat pre cleaner


Grain Cleaner Description Grain cleaning machine (also called Grain Pre Cleaner) is the important grain cleaners, it is designed and manufactured by Shelley Engineering for simple, fast removal of light and heavy (rubble) impurities from grain, corn, soybeans, wheat, rice or fuel whose particles sizes and weighs are different than impurity particle, all the grain and the impunity dust are inputed into the rotating screen cylinder,The inner mesh and the out mesh have different diameters, the grains are isolated and flow out through different exit from the dusts in the continuous screening process. The grain cleaner can also be used for screening soybean meal, soybean meal blocking the bulk through continuous rotation, making the soybean meal block decreasing in monocular state.This kind of grain cleaning equipment reduces the emission of dust into the atmosphere.
Specifications of Grain Cleaning Machine

Item	Model	Capacity for Corn (T/H)	Capacity for Wheat(T/H)	Capacity for Soybean(T/H)	Capacity for Paddy(T/H)	Large impurity cleaning rate%	Small impurity Cleaning rate%	Power (Kw)	Circulating air(m3/h)
1	TQLY100/220	30-50	35-55	40-55	20-30	85	40	2.2	3000
2	TQLY100/320	40-80	50-90	45-90	30-40	85	40	4	4000
3	TQLY100/320-4B	120-180	120-160	120-200	70-90	85	40	2*4	7500
4	TQLY100/400	60-100	70-100	65-100	45-80	85	40	5.5	5500
5	TQLY125/420	75-130	80-120	80-150	55-90	85	40	7.5	6000
6	TQLY125/520	85-150	80-140	80-165	65-110	85	40	7.5	7000

Structure and Main Components of Grain Cleaner MachineThe grain seeds cleaner machine mainly includes feeding inlet,inner screen,outer screen,fine impurity,big impurity etc.
Features of Grain Cleaning Machine


Features of Grain Cleaning Machine
* Suitable to remove light dust or chaff.
* Fan can be situated to cyclone with negative pressure to minimize dust leaks when exhaust ducting.
* Equipped with 4 fitted mounting brackets.
* Fully galvanized construction for outdoor use.
* Triple extraction point for 3 times the performance.
* Fully adjustable internal guides to ensure the best performance on every crop.
* Side viewing panels to see the adjustment effects.
Working Details
When the TCQY series cylinder primary cleaning screen is working, the grain that needs to be cleaned flows from the feed port into the inner screen of the double straight cylindrical screen. Through the rotation of the screen and the material level difference, the material flows in the screen for continuous screening. Therefore, grain and impurities smaller than the sieve hole of the inner sieve tube fall into the outer sieve tube through the sieve holes, while the large impurities larger than the sieve hole of the inner sieve tube stay in the inner sieve tube and flow to the large impurities outlet, which is smaller than the outer sieve tube sieve. The small impurities in the holes flow into the small hopper through the sieve holes, and the grain left in the outer sieve cylinder is pushed forward and falls into the grain output hopper through the rotation of the sieve cylinder and the material level difference; the dust is sucked out through the air duct.
Applications of Grain Cleaner Machine Grain Cleaning Machine is successfully used in the reception of granular, mealy, and floury bulk materials in grain mills, bulk storage systems, and other plants in the food processing and feed manufacturing industries.The drum sieve separates coarse impurities such as pieces of straw, bag tapes, paper, pieces of wood, and grain leaves and cobs, etc.
Grain cleaning machine is applied in food, starch, oil, alcohol and other industries to clean out the dust from the grain. It is widely used in grain storage silos, bulk storage systems, food processing plants or feed production lines.
Packaging and shippment of Grain Cleaner Machine
Usually rain proof plastic film packaging,also can be customized.
Applications of Grain Cleaner Machine Grain Cleaning Machine is successfully used in the reception of granular, mealy, and floury bulk materials in grain mills, bulk storage systems, and other plants in the food processing and feed manufacturing industries.The drum sieve separates coarse impurities such as pieces of straw, bag tapes, paper, pieces of wood, and grain leaves and cobs, etc
TSE certificates
With good quality and service,TSE silos are famous in China and abroad,alsoowned owned many certificates.
Some certificates below are just for your reference
TSE introduction
Taian Shelley Engineering Co.,Ltd is the professional steel grain silos designer and manufacturer dedicated in supplying turn key grain storage and handling solutions to worldwide customers. We have more than 30 talented grain storage solutions experts and 9,000 square meters state-of-the-art factory. Our innovative, high-quality flat bottom silos, hopper bottom silos, powder silos, feed silos, bucket elevators, dust collectors and grain storage control system are integrated as a system to satisfy your grain storage requirements. All of our steel silos can be designed and installed with heat retaining layer to meet your special insulated grain storage demands. Product innovation, quality assurance and customer satisfaction are our long term commitment to worldwide customers. We had been provided grain storage silos, solutions and services for over 50 countries since our foundation by Shelley Jin in 2007. Hope to become your partners.

---
