Electrical Mica Tape Tube for Motor

Product Description

Product Overview
The soft natural mica board is a plate-like insulating material made by bonding and peeling mica sheets with adhesive paint and baking and pressing the patch. The product has neat edges and uniform distribution of adhesive. Insulation and turn-to-turn insulation, as well as other motor electrical insulation.
Product Data

Natural Mica Flakes Physical Properties
Model	HP5M	HP5P	HP5S
Nominal Thickness(mm)	0.1-100	0.1-100	0.1-100
Mica Conent %(≥)	90	90	90
Bond Content %(≥)	10	10	10
Density(g/cm3)	1.8-2.38	1.9-2.40	1.9-2.40
Flexural Strength(N/mm2)	>160	>150	>160
Water Absorption24H/23ºC%(<)	0.5	0.5	0.5
Dielectric Strength KV/mm(≥)	20	20	20
Heat Loss at 500ºC %(≤)	0.5	0.5	0.5

---
