| SPECIFICATIONS |
| RANGE OF OPERATION | Boom Length | 3475mm |
| Arm Length | 1850mm |
| Max Radius Of Capture | 6800mm |
| Grab The Biggest Opening Width | 1200~1500mm |
| Grab The Minimum Opening Width | 100~300mm |
| Maximum Radius Weight Capacity | 0.5~0.6t |
| Grapple Rotation Angle | 360° |
| Max Dumping Height | 4700mm |
| Back-End Radius Of Gyration | 1980mm |
| DIMENSION | (Length*Width*Height) Travel Position | 6000*2100*2850mm |
| Wheel Base | 2400mm |
| Track(Front/Rear) | 1660mm/1580mm |
| Ground Clearance Of Counterweight | 1060mm |
| Min Ground Clearance | 265mm |
| TECHNICAL PARAMETERS | Angle Of Rotation | 360° |
| Machine Weight | 6800kg |
| Engine Model | YN38GB2/4102 |
| Rated Power | 58.8kw |
| Rated Speed | 2200r/min |
| Hydraulic System Working Pressure | 21Mpa |
| Hydraulic system flow | 110L/min |
| Metering gear pump | 2*25ml/r |
| Grapple Swing Speed | 12r/min |
| Walking Speed | 25km/h |
| Grade Climbing Ability | 58%/30° |
| Tyre model | 825.16 |
| Revolution overdrive pressure | 16Mpa |
| Full Circle Swinging Time | 5.5s |
| Fqt Fuel Quantity | ≥4L/h |
| Capacity Of The Fuel Tank | 110L |
| Hydraulic Tank Capacity | 110L |
