| US$10,000.00-70,000.00 | 1 Set (MOQ) |
•ShengHe's Aquatic weed harvesters provide an eco-friendly solution for managing for maintenance of large reservoirs, canals, and ports. •Enables water bodies to maintain circulation. | •Keeps your water bodies clean, and frees your water from the invasion of aquatic plants and garbage. •Prevents siltation and eutrophication of your water bodies. |
| Component | Description |
| Wheels | The aquatic weed harvester is driven by a Light Wheels, which doesn't have the risk of getting stuck by weeds. The Wheel enables to push through heavy weeds or garbage. |
| Hull | The hull of the aquatic weed harvester is designed to be robust and durable, made from high-quality materials to ensure long-lasting performance in various water conditions. With a strong internal framework, multiple airtight compartments that glides effortlessly through the water. Bottom plate thickness: 5mm, Side plate thickness: 5mm, Deck thickness: 4mm. |
| Front Collect Arm | The Aquatic Weed Harvester comes equipped with durable sickle blades that are resistant to corrosion and wear, enabling efficient cutting through even the most resilient weeds. These blades are specifically engineered to minimize weed entanglement and can be easily replaced individually as needed. If it is a garbage salvage ship, the front arm is designed as a collection arm. |
| Operating Room | It has one control room, allowing the entire vessel to be operated by a single person. |
| Model | Overall Size of Boat | Widths | Capacity |
| SH-6-1000 | 6m*2.25m*1.5m | 1.4m | 1000m2/H |
| SH-10-2500 | 10m*4.4m*2.6m | 1.5m | 2500m2/H |
| SH-12-3500 | 12m*4.6m*2.8m | 1.5m | 3500m2/H |
| SH-13-4500 | 13m*4.6m*2.9m | 3m | 4500m2/H |
| SH-15-5000 | 15.5m*4.8m*3m | 3m | 5000m2/H |
| SH-17-8000 | 17m*5.4m*4.6m | 3m | 8000m2/H |
| SH-19-12000 | 19m*5.6m*4.7m | 3.4m | 12000m2/H |
| Property | Description |
| Motor | • Main Diesel Engine : 40 Kw, 1 set • Front collect arm: Hydrauulic motor 1 set |
| Hull | • Hull : Coated with both primer and top, providing corrosion resistance. |
| Dimensions | • Over Size of Boat :10m * 4.4m * 2.6m(LxWxH) • Hull size of boat : 5m * 3m * 0.8m(LxWxH) • Wheel size : 1m * 0.5m |
| Speed | • Work move speed : 3-5km\h • Travel speed : 5-7km\h |
| Areas of application | • Cleaning and maintenance of various water surfaces • Removal of aquatic plants and algae below the water surface • Removal garbage and weed floating on the water surface |
| Conveyor belts | • Chain material : Made of stainless material |
| Cutter | • U-shape cutterbar : with 1.5m working width and 0.6m working depth • Double-knife cutter |
| Standard equipment | • O ring : 1 set • Life jacket : 2 sets • Life buoy : 2 sets • Tool kit : 1 set • Fire extinguisher : 2 sets • Diesel engine filters : 1 set |
| Located in Shandong, China, Weifang Shenghe Environmental Protection Machinery Manufacturing Co., Ltd stands out as a leading manufacturer and trading entity focusing on environmental protection machinery. Our expertise lies in the production of a diverse range of dredgers and associated equipment. Since our inception in 2015, we have operated within a spacious factory spanning approximately 8,000 square meters. | Weifang Shenghe's success is built on a relentless pursuit of quality and innovation. The company holds a number of certifications that demonstrate its commitment to excellence in quality management and environmental management systems. In addition, Weifang Shenghe has strong R&D capabilities, continually developing unique local certified products that not only meet stringent international standards, but also meet the requirements of global customers. |
Service Category | Details |
| Technical Support Service | One-Year Warranty: One-year standard warranty covering major components and labor. 24/7 Technical Support: Lifetime technical support available around the clock. |
| Parts and Maintenance | Spare Parts Supply: Ready stock of essential spare parts, shipped immediately upon request. |
| Training and Installation | Onsite Training: Comprehensive training sessions for operators. |
| Customization and Upgrades | Tailored Adjustments: Customization options for specific environmental conditions or operational needs. |
