CNC Turning Machining Center Tck700b Box Way Slant Bed Lathe Machine

Product Description

Product Description
Products Description:
Detailed Photos
Product Parameters
CNC Turning Machining Center TCK700B Box Way Slant Bed Lathe Machine
Performence Features:
The machine is suitable to process all kinds of small and middle-sized shaft and plate work piece, and could also turn various threads, circle arc, circular arc ,circular cone,inside and outside surface of revolved body.
This machine is widely used in sanitary,valve ,electrical
appliance,instrument,automobile,motorcycle, bearings and so on.
Higher accuracy box guideways.
High speed spindle unit.
Higher rigidity cast iron.
Integrated automatic lubrication
30 degree One-piece casting slant bed.
Technical parameter:

Specifications	TCK700B
Max.swing over bed (mm)	Φ730
Max.turning diameter (mm)	Φ560
Max.swing over cross slide (mm)	Φ440
Max.turning length (mm)	630
Spindle nose	A2-8
Chuck size	10"
Spindle motor power (kw)	15
Max.spindle speed (rpm)	2500
Spindle bore (mm)	Φ87
Max turning Dia Bar (mm)	Φ75
X/Z axis leadscrew (mm)	40/50
X axis limit Travel (mm)	330
Z axis limit Travel (mm)	940
X/Z axis motor torque (N/m)	22/22
X/Z axis accuracy (mm)	0.008
X/Z axis repeat accuracy (mm)	0.005
Tailstock quill diameter (mm)	Φ100
Tailstock quill travel (mm)	80
Tailstock travel (mm)	785
Tailstock taper	MT5
Machine dimension (mm)	3170x1180 x1700
Weight (kg)	4500

Standard Accessories
Standard accessories

Fanuc 0i TF plus controller

Main motor and servo motor from Fanuc

Ball leadscrew from PMI or Hiwin

10 inch Hollow hydraulic chuck

Foot switch for chuck clamp and tailstock

Hydraulic tailstock

Hydraulic stations

Hydraulic turret 12 tools

4 tool seat (1 external,2 internal,1 boring)

Telescopic covers

Full closed cover

Coolant system

Lubricating system

Work lamp

Tri-color alarm lamp

Safty door

USB interface

Chain type chip conveyor

Air gun + Water gun

Schneider electric components

Live center

Tools and tool box

English Manual

Optional accessories
Optional accessories

Power turret BMT65

Extra Radial live head

Extra Axial live head

C axis Function

Y axis travel ±45mm

Part catcher

Servo type bar feeder

Tool measurement probe Renishaw

Hydraulic programmable tailstock
