6: 1 8ton Blue Polyester Webbing Slings Chain Sling

Product Description

Product information
Stronger heavy duty G80 steel sling strap hook

1. Material: high quality alloy steel 2. Surface treatment: self-coloring, polishing, oxidizing black, hot dip galvanizing, etc
3. Quality grade :G80, G100
4. Safety factor: 4 times at least

Please advise strength class (M(4), S(6) or T(8)), diameter (6mm-32mm) and asphalt, finish (self coloring, polishing, painting, blackening, plastic coating, galvanizing). If chain sling is required, such as single leg chain sling, double leg chain sling, three leg chain sling or four leg chain sling.
In general, the main connecting rod assembly is used for one - or two-leg chain slings, and for three - or four-leg chain slings.
Product specification

Dia of meter rated load t			Master Link	Weight	Weight per meter
mm	α ≤45°	45°< α ≤60°	A × B × D	Kg	Kg/m
6	2.1	1.5	80x150x20	7.33	0.79
8	3.1	2.2	90x160x24	12.21	1.38
10	5.2	3.7	100x190x28	23.42	2.2
12	7.3	5.2	100x190x28	33.77	3.1
14	10.5	7.5	120x230x34	40.54	4.13
16	12.6	9	135x250x38	53.51	5.63
18	16.8	12	140x270x42	64.47	6.85
20	21	15	160x310x46	79.88	8.6
22	25.2	18	180x330x52	150.42	10.2
24	29.4	21	180x330x52	155.75	12.78
26	35.7	25.5	180x330x56	253.27	14.87
30	46.2	33	210x410x62	268.64	19.6

As for the end of the chain, we can provide you with the following accessories.
For example: eye hook with safety hook, eye hook with turning hook, head hook, eye hook with self-locking hook, eye hook with self-locking hook, eye hook with self-locking hook, rotating self-locking hook, shortening clutch, hook hook, hook hook with safety locking hook, hook hook with self-locking hook, head hook hook, hook hook with safety locking hook.
The main products are wire rope sling, webbing sling, woven sling, ratchet sling, traction sling, sling chain sling, steel plate sling, sling beam, sling accessories. Products are widely used in machinery, metallurgy, petroleum, chemical, port, shipping and other fields.
Our mission: Our goal is to satisfy our customers with quality products and services. We will continue to uphold the "quality first, reputation first, reasonable price" service concept.
Product attention and use:
1. Must be used within its rated load range
2. Twisted, reversed and entangled chains are not allowed.
3. The object must be hung at the center of the hook, not at the edge of the hook. Heavy objects should not be hung on hooks for long periods of time.
4. Stop using the chain immediately if one of the following situations occurs:
A. Diameter damage is 10% of the original size;
B. Cracks, bending, deformation or surface damage of the chain (phenomenon);
C. Permanent extension of chain exceeds 5% of original length.
Why choose us
Quality first, customer first.
1. Any enquiry will be answered within 12 hours.
2.Our price is competitive because we are original manufacturer.
3.OEM/ODM is acceptable.
4.We have strict testing and QC system to ensure the quality.
5. Your business relationship with us will be confidential to any third party.
6. Good after-sales service, all products have a one-year warranty
