Contec RS01 medical device Respiration sleep motitor

Product Description

Product Description
Product Description
Introduction
The RS01 device is suitable for the one who suffers with such diseases as SAHS (sleep apnea-hypopnea syndrome), Its functions including patient’s sleep apnea monitoring and SpO2 monitoring, which can be applied in hospital or at home.

Performance	Nose air flow measurement range	0 rpm~40 rpm, accuracy:±2 rpm
	SpO2 measurement range	0%~100% (resolution 1%),accuracy:70%~100%, ±2; less than 70%, unspecified.
	PR measurement range	30 bpm~250 bpm, accuracy:±2 or ±2% (whichever is greater).
	Resistance to surrounding light	The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
	Power consumption	≤100 mA.
	Power supply	3.7 V rechargeable lithium battery.
	Safety type	internally powered equipment, type BF applied part.
Accessories	A power adapter
	A USB data line
	A Nasal cannula
	Two kinds of SpO2 probes
	A CD (PC software)
	A User Manual
Physical characteristic	Dimension	69 mm (L)×50mm (W) ×17.3 mm (H)
	Weight	about 100g
	Working environment
	Temperature	10 ℃ ~ 40 ℃
	Relative humidity	≤75 %
	Atmospheric pressure	700 hPa~1060 hPa
	Storage environment
	Temperature	-40 ℃ ~ +55 ℃
	Relative humidity	≤95 %
	Atmospheric pressure	500 hPa~1060 hPa

Features
1) SpO2 and PR value display, pulse sound and bar graph indication.
2) Pulse waveform and nose flow waveform display
3) Alarms for low power, finger out and exceeding limits
4) Battery status indication
5) Real-time clock
6) Timing power on/off
7) Storage of multiple cases
8)Continuous 12 hours data record
9)Uploading data via USB port
10)PC analysis software

---
