Advanced Solar Panel Tools for Efficient Semiconductor Cutter Operations

Product Description

Equipment Use: Meticulously crafted for unparalleled cutting efficiency, this remarkable model showcases an impressive roller length of 690mm. The table offers generous dimensions of 170/145mm*690mm*160mm*2, enhancing its capability to expertly slice products with a thickness spectrum of 0.3mm to 65mm. This makes it the quintessential tool for applications demanding precision cutting.
CHTXQ-690F Double Plate Multi-Wire Cutting Machine Product Features
1. This machine features four independently operated motors, each managing one of the four rollers, substantially reducing steel line wear and prolonging roller life. The roller bracket's precisely engineered mounting holes ensure flawless spindle alignment, lending to a seamless and efficient operation.
2. A state-of-the-art LED display provides cutting data that is not only precise but also remarkably easy to interpret, elevating the user experience.
3. A distinctive bottom-up material feeding system allows for effortless loading and unloading, effectively streamlining the entire cutting operation for maximum efficiency.
4. Available in both high-speed and standard configurations, the high-speed model boasts improved line speed and cutting efficiency, making it perfect for applications requiring finer diamond lines.
5. With transverse movement capabilities, the versatile table can move back and forth, adeptly enabling tile cutting and offering a single-line cutting function, adding to its multifunctional prowess.
6. The expansive loading area of 170/145mm*690mm*160mm*2 significantly elevates cutting efficiency, accommodating a wider array of cutting tasks.
7. Spindle precision is meticulously maintained at ≤0.01mm. The machine's patented dust-proof structural design (Patent No. ZL201320681902.7) guarantees stability and simplifies maintenance.
8. Designed for user-friendliness and efficiency, this machine boasts an automatic lifting shield and a fully expandable workbench, streamlining the handling of materials and rolls.

	unit	parameter
Maximum Worksize	mm	170/145*690*160*2
cutting thickness	mm	0.6~65
running speed	m/min	0~2200
Table lift stroke	mm	220
Table cutting feed speed	mm/hour	0.1~100
The amount of wire output from the supply wheel	Km	30(φ0.2diamond wire)
Diamond diameter	mm	φ0.06~φ0.35axle
Roller outside diameter*number of axles	mm	φ155/φ180*690*4
boundary dimension	mm	≈1830*2800*2650
machine weight	Kg	6500~115000
power		AC380V/50HZ three-phase four-wire
Total machine power rating	Kw	54 above

This cutting-edge double-station multi-wire cutting machine, equipped with diamond wire processing, empowers users to process two plate materials per cycle with ease. It features a roller length of 690mm and a cutting area of 220mm*690mm*160mm*2. The rotary tool holder accommodates blade thicknesses from 0.5mm to 65mm, offering flexibility for both single-line and multi-line cutting, particularly for hard and brittle materials.
This model is expertly designed as a multi-line cutting machine with diamond line processing, featuring a roller length of 570mm and a maximum cutting area of 220mm*570mm*160mm. The rotary tool holder is perfectly suited for cutting products with thicknesses ranging from 0.3mm to 65mm, making it ideal for bulk processing of hard and brittle sheets.
This compact multi-line cutting machine, available in both single and double station configurations, is masterfully engineered for small batch straight sheet processing. Its adaptability allows for quick and effortless specification changes, accommodating sheet thicknesses from 0.5mm to 30mm, and supporting both single and multi-line functions for handling small batches of hard and brittle materials.
>Stable Wire Web Control
Revolutionary cone-positioned rollers and wire spools deliver unmatched accuracy and rigidity, significantly reducing wire web oscillation, ensuring precision and reliability.
>Optimized Pulley System
An innovative 8-pulley design effectively minimizes diamond wire torsion, tension fluctuation, and breakage rates, guaranteeing consistent and reliable performance.
>Easy Wire Winding
The wire pay-off wheel utilizes a universal PV600 reinforced I-wheel spool, effortlessly eliminating the need for rewinding and simplifying wire management.
>Safety Guarantee
The main operation door is equipped with an electric lift and a comprehensive safety mechanism, providing robust assurance for operator safety.
>Wire Break Memory System
>Easy Operation
Open on three sides, the cutting room design promotes straightforward operation and easy maintenance access, ensuring user convenience and operational efficiency.

---
