Basic Info.
Model NO.
ER012HDTW&ED002HDID
Color
Optional White/Black
Voice Service
With Voice Service
Installation
Surface-Mounted
Certification
RoHS, CCC, FCC, CE, ISO9001
Screen
7" Color Digital Screen
Indoor Monitor Unlock Release
Supports
Outdoor Panel Unlock Release
Supports
Max Length of Line Connection
100meters
Signal Support
800tvl/ 1080P
Signal Formats
CVBS / Ahd
Power Supply
AC100-240V 50/60Hz DC15V, 12W
Power Consumption
9W(Max), 2.5W(Standby)
Motion Detection
Supports
Mobile APP
Tuya Smart (Ios, Android)
Transport Package
10PCS/CTN
Specification
48.7x34x27cm
Production Capacity
50, 000sets/Month
Packaging & Delivery
Package Size
48.70cm * 34.00cm * 27.00cm
Package Gross Weight
13.510kg
Product Description
Product Description
Detailed Photos
Product Parameters Specification:
Monitor:
| Screen | Color TFT touchscreen |
| Screen size | 7'' |
| Outdoor panel unlock release | Supports |
| Indoor monitor unlock release | Supports |
| Definition | 1024*600 |
| Type of signal | CVBS/AHD |
| Connection | 4 Wires |
| Maximum length of line connection | 100m |
| Video channels quantity | 4 |
| Additional monitors quantity | 3 |
| Memory block connection | Built-in reader for micro SD card |
| Image capture | Supports |
| DVR with both video and audio | Supports |
| Power | DC15V/0.8A |
| Dimension | 188x136x22mm |
Doorbells:
| Subscribers quantity | 1 |
| Camera | 1/2.9'' Color CMOS |
| Angle of view | 120° |
| Protection Standard | IP66 |
| Type of signal | CVBS / AHD |
| Resolution | 800TVL/1080P(Optional) |
| Construction | Surface / 30° angled mounting |
| Operating temperature | - 30 ºC to + 60ºC |
| Connection | 4 wires |
| Lock control | Supports |
| Card Support | Em marine (ID) / Mifare (IC) |
| Compatible working | WG26 |
| Power | DC10-15V |
| Dimension | 131x46x20mm |
All our models have passed CE, RoHS, and REACH certificates, and with 2 2-year warranty, you are welcome to visit our factory or take samples to test our quality.
Company Profile
FAQ Q: Can i get a sample to test first?
E: Yes, you are welcome to take samples to test our quality at anytime.
Q: Can you do OEM / ODM for customers?
E: Yes, we do OEM & ODM service, we also do LOGO, Giftbox designs, any design as your like. Q: What's your MOQ?
E: it's no MOQ for neutral models. The MOQ is 300PCS/Model to print your logo & giftbox.
Q: How about your lead-time?
E: It's 2-5days for samples; It's about 25 working days after get your deposit for bulk order.
Q: What's your warranty for your products?
E: 2 years after the shipment.
>>
