| -Internal Size(L×B×H) | 18000 x 4900x 4500 mm |
| -External Size(L×B×H) | 19240*5000*H5000mm(including the rear of the fan unit) |
| Wall and Door | |
| - Steel Wall | Six-span gantry, the wall panels are machine-composite rock wool composite sandwich panels. Filled with 80K rock wool, gray andwhite total thickness T=50mm |
| - Roof Panal | The top sealing plate is folded with galvanized sheet Primary color of galvanized sheet |
| - 4Folded Entrance Door With Safety Glass Window | 1 set 40% off, door size is 4000*4300mm (W x H) full sheet metal door, tempered glass. |
| - Operator's Door With Safety Glass Window | 1 piece, 800x2000mm (W x H) off-white with pressure lock, tempered glass. |
| Lighting | |
| Ceiling Lightings | 18 groups of 4x 18W each, total 1296W |
| Side Lightings | 12 groups, each group of 2x18w, a total of 432w |
| Brightness | ≥1000 LUX |
| Direct Drive Motor (Fresh Air) | 1 set of 7.5kw intake fan 1 set 7.5kw exhaust fan One set has a large circulating air door, an aluminum alloy three-way frame structure, and a 25mm thickness insulation box. |
| Heating System | |
| - Heating Exchanger | Heating wire |
| Max. Drying Temperature | 80 °C |
| - Heating Exchange Capacity | 8 groups, each group 9KW , a total of 72KW |
| Control system | Fully intelligent control, fault alarm, operation indication, one-key setting of paint temperature and time, with pressure controlsystem. |
| Accept non-standard customization | |
