HAWKER | The traction forklift battery produced by Hawk Power Supply Co., Ltd. is currently advanced in technology and technology, and is also widely used in the industry. For example, many famous brand manufacturers such as forklifts, locomotive tractors, electric cleaning vehicles, and electric tour buses all use HAWKERPZS traction batteries. It conforms to DIN standards, mainly supporting European standard forklift trucks such as LINDE, HANGCHA, JUNGHEINRICH, HYSTER, BT, STILL, etc. It conforms to JIS/BS standards, and is mainly equipped with JIS/BS standard forklift trucks such as NICHIYU, TOYOTA, TCM, KOMATSU, SHINKO, NISSAN, etc.
Monomer structure
HAWKER traction battery uses mature tubular positive plate technology. The positive plate adopts die-casting grid, and the active material is stored in the manifold made of polyester material; The negative plate uses reinforced plate type plate. There are many micropores between the positive and negative plates, and there is a convex diaphragm on one side. The shell of the battery monomer is made of polypropylene material with high impact resistance and high temperature resistance, and the shell cover is heat sealed to prevent the leakage of electrolyte.
Pole terminal
Each positive and negative terminal is cast with lead alloy and copper core terminal with internal thread. The combination of the pole and the compressed sealing rubber ring can effectively prevent the leakage of the electrolyte.
Single battery connection strip
The cells are connected by fully insulated halogen-free flexible connection strips. The way of fixing the connecting strip with bolts can make it easy and fast to take out the monomer from the battery pack for maintenance or replacement.
Safety valve
Each cell is equipped with a safety valve to allow the gas generated during charging to escape. The operation of adding purified water and measuring the specific gravity of electrolyte can be carried out through the safety valve. The safety valve also has a baffle for battery to prevent electrolyte surge.
Battery cover
The battery cover is designed to install electrolyte stirring system or temperature sensor after punching.
Hawker Aquamatic centralized automatic water filling system
Hawker Aquamatic centralized automatic water filling system can add water to all battery cells in the battery pack from the central point of the battery system. As shown in the previous figure, the water filling safety valve of the system can automatically maintain the optimal liquid level of the battery monomer, and also allow the gas generated during charging to escape and measure the specific gravity of the electrolyte.
Electrolyte agitation system
Hawker electrolyte circulating agitation system is based on the principle of air lift and uses the pipeline system installed on the battery to work. The diaphragm pump blows the low-speed air flow into the battery, so that the air flow circulates in the battery shell. The system can effectively prevent electrolyte delamination and ensure charging optimization.
>>
