ASTM B363 Titanium Pipe Fittings, Including ASTM Sb363, Wpt12, and Gr12 Types.

Product Description

Quick Details

Material:	Titanium	Technics:		Type:	Elbow
Place of Origin:	China	Model Number:	45°,90°,180°	Brand Name:	C&N
Connection:	Welding	Shape:	Equal	Head Code:	round
color:	Silvery White	application:	petroleum, gas, chemical industry, metallurgy, pharmacy,	standards:	ASTM B363, ASME B16.9
character 1:	corrosion resistance	characteristic 2:	Rustless

Packaging & Delivery

Packaging Detail:	plywood box/wooden pallet/customized
Delivery Detail:	10~40 days

Specifications
seamless titanium elbows
1.Specification: 45D,90D,180D
2.ASME B16.9 , ASTM B265, SB265,AMS,JIS
OD:5.0~300xW
We offer titanium elbow in any type and we can supply it at per clent's requirements
seamless titanium elbows
titanium elbow :
1)Name:pure titanium elbow
2)Standard: ASME/ANSI B16.9
3)Material:Gr1,Gr2,Gr3,Gr4,Gr5,Gr6,Gr7,Gr9,Gr12,Gr23ETC.
4)Size : (45D,90D,180D) NPS1/4''-24'' Wall thickness:SCH5S-SCH160S

Element	Composition,%
	Grade1	Grade2	Grade3	Grade4	Grade5	Grade6	Grade7	Grade9	Grade11	Grade12
N max	0.03	0.03	0.05	0.05	0.05	0.03	0.03	0.03	0.03	0.03
C max	0.08	0.08	0.08	0.08	0.08	0.08	0.08	0.08	0.08	0.08
H max	0.05	0.015	0.015	0.015	0.015	0.015	0.015	0.015	0.015	0.015
Fe max	0.2	0.3	0.3	0.5	0.4	0.3	0.5	0.25	0.2	0.3
O max	0.18	0.25	0.35	0.4	0.2	0.2	0.25	0.15	0.18	0.25
Al					5.5-6.75	4.0-4.6		2.5-3.5
V					3.5-4.5			2.0-3.0

5)Application: Used in petroleum, gas, chemical industry, electric power, metallurgy, pharmacy, shipyard and other similar yield.
6) thiness : 0.5-8mm
7)Inner diameter: 6-108mm
8) Certification: ISO9001-2008

Titanium Elbow,Titanium Pipe Fittings,Titanium Fittings,Seamless Titanium fittingsmaterialTitanium Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9standardASTM B363,,ASTM SB363,ASTM B16.9Titanium elbowElbows (45D, 90D, 180D) NPS 1/4" - 24"(DN5-1200)Reducersconcentric, eccentric,NPS 1/4" - 24"(DN15-1200)Tees(straight, reducing) ,NPS 1/4" - 24" (DN15-1200)Stub endsNPS1/4" - 4"Wall thicknessSCH5S-SCH160S (1-15mm)Caps, flingers, socket welding fittings, valves availableTechnicalPressing,welded, seamlessMaterial Test ReportEN10204.3.1,Chemical Composion And Physical PropertiesProduct MarkingAll products are marked by laser after they are finishedProducts Types45°Titanium elbow,90°Titanium elbows,Titanium Tee,Titanium Reducer,Titanium Weldolt,Titanium End Cap,Titanium Stub End.CertifcateGermany TUV Assessment, ISO9001:2008

Custom manufacturing and OEM service available
Looking forward to having a good cooperation!

---
