Wet Dry Liquid Powder Groove Type Blender Trough Shape Double Paddle Mixer Trough Mixer

Product Description

Product Description The trough type mixer is based on the transmission trough mixer of our company. It has made many improvements to the mixing paddle, sealing and unloading, which makes the operation more convenient and the cleaning is more thorough. More widely used.

Features • This machine uses two motors, a stirring motor, which drives the mixing paddle to rotate the mixture material through the shaft. A discharge motor can be used to tilt the stirring tank to facilitate unloading.
• There are one-way thrust ball bearings and radial thrust ball bearings at both ends of the stirring shaft to prevent radial turbulence caused by negative stress.
• The sealing at both ends of the mixing shaft has been improved, and it can be completely sealed without contaminant material.
• When jogging is used, it is easy to discharge, and it will not cause the phenomenon that the hopper tilts too much. The left end of the machine rotates. Because the worm wheel and the worm drive have self-locking effect, the mixing box can be dumped at any angle.
• Add the raw material to the cylinder at one time, dry it for a period of time, add the adhesive or spray the liquid, or add the raw material and the adhesive to the working container at one time, and mix it into the ideal soft material.

Applications • Mixing of the previous steps in the production of tablets and granules in the pharmaceutical industry.
• Mixing of the food industry, such as condiments, dairy products, spices, cakes, etc.
• Mix of feed production.
• Mixing of powders and liquids in the chemical industry.
Product Parameters

Model	CH-100	CH-200	CH-300	CH-400	CH-500
Total Vol (L)	100	200	300	400	500
Paddle Speed (rpm)	24	24	24	20	20
Main Motor (kw)	2.2	4	5.5	7.5	7.5
Discharge Motor (kw)	0.75	0.75	1.5	1.5	1.5
