| US$23,000.00 | 1 set (MOQ) |
| Technical Parameters | Model UP-230T PET | ||
| Injection Unit | A | B | C |
| Screw diameter (mm) | 50 | 55 | 60 |
| Shot Volume (cm3) | 461 | 558 | 664 |
| Injection weight (g) | 553 | 669 | 796 |
| injection pressure (Mpa) | 169 | 142 | 121 |
| Screw speed (rmp) | 155 | ||
| Clamping Unit | |||
| Clamping force (KN) | 2300 | ||
| Open stroke (mm) | 475 | ||
| Max Mold height (mm) | 550 | ||
| Min Mold height (mm) | 220 | ||
| Space between tie bars(mm) | 530*530 | ||
| Ejector force (KN) | 70 | ||
| Ejector stroke (mm) | 135 | ||
| Others | |||
| Pump pressure (Mpa) | 16 | ||
| Motor/driving power (KW) | 22(21.2) | ||
| Heating power (KW) | 14.2 | ||
| Machine dimension (M) | 5.8*1.55*2.15 | ||
| Machine weight (T) | 6.3 | ||
| Oiltank cubage (L) | 350 | ||
