Filled PTFE for Mechanical Seal

Product Description

Filled PTFE Parts
PTFE has excellent properties and is widely used in industrial sealing, electronics, chemical and other fields.
Cierne Mechanical provides a wide range of PTFE plates, rods, tubes, case and CNC machining products. Filled PTFE Profile

FILLER ELEMENT	FEATURE	USAGE
GLASS FIBER FILLED PTFE	Strong wear resistance, small friction, excellent electrical performance.	Mechanical and electrical, such as bearings, gaskets, gasket sheet
GLASS FIBER & GRAPHITE FILLED PTFE	Wear resistance, low friction, and creep reduction	Mechanical, such as piston ring, bridge groove, tube bearing pad, not suitable for electrical products
GLASS FIBER & MOS2 FILLED PTFE	Strong wear resistance, small friction, small creep, excellent electrical performance	Mechanical and electrical applications, such as split bearings, valve seats
CARBON FIBER FILLED PTFE	Wear resistance and load resistance	Mechanical applications such as bearings, mechanical seals and bearing pads
GRAPHITE FILLED PTFE	Small friction, good drug resistance, creep smaller	Machinery and pharmaceutical industries, such as bearings, gaskets, gaskets
BRONZE FILLED PTFE	Wear resistance, low friction, high thermal conductivity	Mechanical, such as piston ring, bridge groove, tube bearing pad, not suitable for electrical products

Filled PTFE Technical Data

FILLED ELEMENT OF COMPOSITION PTFE MATERIAL	GRAVITY	HARDNESS	TENSILE STRENGTH	ELONGATION	COMPRESSIBILITY
	ASTM D4894	ASTM D2240	ASTM D4894	ASTM D4894	Internal
	g/cm³	Shore D	MPa	%	%
15%GLASS FIBER FILLED PTFE	2.20-2.24	59-61	23-25	330-360	2.0-2.7
20%GLASS FIBER FILLED PTFE	2.20-2.24	60-65	16-19	290-340	2.0-2.7
25%GLASS FIBER FILLED PTFE	2.22-2.26	60-65	14-17	250-290	2.0-2.7
15%GLASS FIBER + 5%GRAPHTE FILLED PTFE	2.20-2.25	60-65	17-20	260-290	2.0-2.7
15%GLASS FIBER + 5%MOS2 FILLED PTFE	2.24-2.29	60-65	22-24	250-300	2.0-2.7
15%CARBON FIBER FILLED PTFE	2.05-2.15	60-65	18-22	300-340	2.0-2.7
15%GRAPHITE FILLED PTFE	2.15-2.19	55-60	19-23	270-320	2.0-2.7
60%BRONZE FILLED PTFE	3.85-4.00	65-70	15-17	200-250	2.0-2.7

Qingdao CIERNE Mechanical Part founded in 2010,located in beautiful Laoshan disctrict following the high technology of Cierne Slovakia.Our company mainly managed in spiral wound gaskets,PTFE gaskets,high temperature graphite gaskets,expanded PTFE gaskets,filled PTFE sheet,graphite sheet,Non asbestos sheet,disc spring,and other mechanical parts and valve,pump using gland packing.
We have large stock all the year around and we compete with good price,quick delivery, enthusiastic aftersale service to serve our customers around the world. Our all products are widely using in Metallurgy,Chemicals,Petrol Chemical industry,Electric industry,shipbuilding industry and others. We cooperate with main manufactures this field and exports our products to Europe,Southeast Asia,Africa,etc and get good feedback.Extremely good sealing performance; Non asbestos gasket working in top temperature upto 800ºC. Production technology in the international leading level, material can help plant save cost.
Our Tenet:
Listen carefully to customers requirement. Build products quality with heart. Provide satisfying service with honest Remember good after-sale service is the only reason we live. Raw Material The self-developed advanced production equipment meets the diversified demands of products and saves cost and materials for users.
Technical Assistance Efficient machining center to provide customers with a variety of conventional and unconventional quality sealing components, to speed up the production cycle, improve delivery speed.
R & D Capabilities We have signed contracts with many express companies, such as Fedex, UPS, TNT, so as to facilitate various transportation needs and make transportation more rapid and convenient.

---
