| US$7,543.00-9,051.00 | 1 Piece (MOQ) |
| MODEL | CF100M-7 | CF185M-7 | CF275M-7 | CF400M-7 | CF390M-10.5 | CF830M-10.5 |
| Air End Type | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage | Rotary Twin Screw, Single stage |
| Air Outlets | 3/4'' x 2 | 3/4'' x 3 | 3/4'' x 2 + 1-1/4'' x 1 | 3/4'' x 3 + 2' x 1 | 3/4'' x 3 + 2' x 1 | 3/4'' x 1 + 2' x 1 |
| Free Air Delivery | 100 CFM / 2.8 m3/min | 185 CFM / 5.2 m3/min | 275 CFM / 7.8 m3/min | 400 CFM / 11.2 m3/min | 390 CFM / 11 m3/min | 830 CFM / 23.3 m3/min |
| Working Pressure | 7 bar / 101.5 psi | 7 bar / 101.5 psi | 7 bar / 101.5 psi | 7 bar / 101.5 psi | 10.5 bar / 152.25 psi | 10.5 bar / 152.25 psi |
| Fuel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel |
| Emission | China Stage II | China Stage II | China Stage II | China Stage II | China Stage II | China Stage II |
| Engine Type | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection | 4 cylinder, Direct-injection |
| Displacement | 2.771 L | 2.771 L | 2.771 L | 3.9 L | 5.9 L | 8.9 L |
| L X W X H | 3066*1456*1587 mm | 3180*1630*1600 mm | 3530*1760*1770 mm | 4155*2025*1890 mm | 4370*1950*2355 mm | 3066*1456*1587 mm |
| Weight | 900 kg | 1120 kg | 1450 kg | 1850 kg | 2070 kg | 4400 kg |
| Note: Please feel free to contact us if any more customized requirements ! | ||||||
