Medical Fully Automatic Large Capacity Pure Steam Sterilizer Autoclave Machine

Product Description

Medical Pure Steam Sterilizer
Product Application
This series of pure steam sterilizers is suitable for running in hundred-grade clean range and other high-standard site. It is used for treatment of biological products, utensils, sterile gown, medical appliance, medical dressing and articles without heat source on the basis of moist heat sterilization. It adopts touch screen, PLC, miniprinter to inspect pressure, temperature and print records for whole sterilization course, conforming to the requirements of national GMP specification.

Steam Pressure: 0.3-0.5Mpa
Designed Pressure: 0.25Mpa
Water pressure: 0.15-0.3Mpa
Working Pressure: 0.23Mpa
Compressed Air Pressure: 0.5-0.7Mpa
Working Temperature: 134ºC

Main Features
1. The inner chamber is made of 316L or 304 stainless steel, the jacket is made of 345R material special for pressure vessel. Stainless steel wiring-drawing plate for decoration case. There is GMP confirmation port access for the users to confirm the equipment.
2. Steam enters the sterilizer via two pipelines. The inner chamber is fed with pure steam, whose pipelines, valves and instruments are made of316L material. The jacket is fed with industrial steam, whose pipelines are made of 304 stainless steel
3. Completed functions of recording, printing and storing. Temperature, time and pressure graph can be printed.
4. Two ways recorders.
5. Traceability of the manufacturing process and program control.
Technical parameter

Model	Inner Chamber size(L x W x H)	Overall Size(L x W x H) single/double Door	Net Weight kg	Boiler Steam consumption kg/cycle	Pure Steam consumption kg/cycle	Control Power AC220/50Hz/kw	Power supply 3-AC380/50Hz/kw	Water consumption kg/cycle
MR-CZQ-0.24	670X600X600	950x1350x1800 1010x1350x1800	600 700	15	10	0.5	1.5	50
MR-CZQ-0.36	1000X600X600	1280x1350x1800 1340x1350x1800	700 800	18	15	0.5	1.5	60
MR-CZQ-0.6	1170x610x910	1450x1350x1900 1510x1350x1900	1100 1250	25	20	0.5	2.4	70
MR-CZQ-0.8	1450x610x910	1730x1350x1900 1790x1350x1900	1250 1400	27	23	0.5	2.4	70
MR-CZQ-1.0	1250x680x1180	1530x1450x2000 1590x1450x2000	1400 1550	30	25	0.5	3.0	80
MR-CZQ-1.2	1500x680x1180	1780x1450x2000 1840x1450x2000	1700 1950	35	30	0.5	3.0	80
MR-CZQ-1.5	1870x680x1180	2150x1450x2000 2210x1450x2000	1900 2150	40	35	0.5	4.0	90
MR-CZQ-2.0	1700x1000x1200	2040x1800x2000	2400	50	40	0.5	4.0	100
MR-CZQ-2.5	1700x1000x1500	2040x1800x2200	2700	60	45	0.5	4.0	100
MR-CZQ-3.0	2000x1000x1500	2340x1800x2200	2950	70	50	0.5	5.5	120
MR-CZQ-4.0	2670x1000x1500	3010x1800x2200	3600	85	55	0.5	5.5	120
MR-CZQ-5.0	3340x1000x1500	3680x1800x2200	4900	100	60	0.5	7.5	140
MR-CZQ-6.0	4000x1000x1500	4340x1800x2200	5600	115	65	0.5	11	140
