| US$142.00-165.00 | 1 Piece (MOQ) |
| Product number | FST100-2008 |
| Measuring range | Rain intensity range: 0.01mm~4mm/min (allowable maximum rain intensity 8mm/min) |
| Output signal | RS485 output (Modbus protocol) pulse |
| Supply voltage | Analog signal: 12~24VDC Digital signal: 5~24VDC |
| Maximum power consumption | Static 0.16W Dynamic 1.8W |
| Precision | Accuracy ≤±3% |
| Resolution | 0.2mm |
| Operating temperature | -10~50ºC Relative humidity<95% (40ºC) |
| Device address | 1~255 can be set, the default is 1 |
| Device baud rate | Standard MODBUS-RTU protocol, baud rate 9600 |
| Byte format | 8 data bits, 1 stop bit, no parity |
| Electrical connections | Direct lead |
