Automatic Silicone Rubber Vulcanizing Molding Compression Plate Heat Hydraulic Press Vulcanizer Machine with CE Certificate

Product Description

200Ton double working station rubber and silicone molding machine, hot press machine, with double pump and 3 layer open mould style, high precision, full automatic, fast speed hydraulic machine.
Machine main feature:
1. With proofread slow speed of mold function, proofread mold more accurate, more secure
2. Suitable for variety 2-layers or multi-layers molds, it is a kind of new multi-function machine
3. Adopt dual power individual circuit design, stable, quiet, low failure rate, two axes can be operated simultaneously
4. With adjustable slow speed of mold features to suit different types of modules
5. Out-In mold positioning accuracy, positioning 100% security, to ensure that mold does not damage

Applicable products:
Applied to industrial rubber parts, Auto parts, medical bottle stoppers, household ware, cookware, silicone/rubber multi-layer molded products
Main Parameter:

Type	100Ton	100Ton		200Ton		250Ton		300Ton		350Ton		500Ton
Clamping force (Ton)	100	100		200		250		300		300		500
Stroke (mm)	270	270		300		300		300		300		300
Heating plate size (mm)	400*400	500*500		560*560		600*650		650*650		750*750		1200*1000
Diameter of cylinder	250	250		355		400		450		475		560
Motor power (hp)	5*2	5*2		10*2		10*2		15*2		15*2		15*2
Type of mold opening	2RT/3RT/4RT Up down in /Out 2RT/3RT/4RT
Double shaft thermal electricity (kw)	15.6	25		27		34		38		40		86
Total power (kw)	23	32.5		42		49		60		62		108
Weight (kg)	4500	5500		7000		9000		11000		13000		25000
Dimension (L*W*H)mm	2500	2800		3000		3400		3450		3450		4700
	1800	2100		2400		2500		2500		2600		3860
	1700	2000	2000		2050		2100		2100		2280

Packing & Shipment:
About Dahua :
Qingdao Dahua Machinery Co.,Ltd. which was established in 2000 is affiliated to Shandong Rubber Machinery Research Institute.We specialize in scientific research,production and sales of Rubber Machinery.As keeping extensive close cooperation with Qingdao University of science and technology,Shandong University,China University of petroleum,Chinese Academy of Sciences we have made a great contribution to the development of China Rubber Machinery.
The company has experienced technical team,earnestly the grass-roots staff.We have advanced CNC machines and a variety of large and small mechanical processing equipment,heat treatment equipment and sophisticated detection equipment and introduced advanced UG 3D mechanical design software and performance optimization software in 2006. Our design team can design and manufacture non-standard rubber machinery according to customer requirements.
"Quality first, technology innovation" is the company's business principle,our products were rated as "excellent provincial famous brand" ,"free products" and exported to many countries and regions such as United States,Germany,France,Canada,Australia,South America and so on.With excellent quality and good customer service, the products have been well received among domestic and foreign customers!
We sincerely welcome customers all over the world to visit our company or call us to have a business negotiation, hope to make a good faith and win-win cooperation with you and common development hand in hand.
Customer Show:
FAQ:
Q: Are you manufacturer or trade company?
A: We are really 100% manufacturer.
Q: How many year's experience does your company have?
A: More than 20 years of concentration, we mastered several key technologies.
Q: What product can you supply?
A: Rubber press machine, Vacuum molding press machine, Injection Molding machine, Rubber mixer machine, calender machine, extruder machine and rubber product equipment solvtions.
Q: What are the operating modes of the machine?
A: With manual and semi-automatic operation mode.
Q: What control system does the machine use?
A: We use PLC as the core of control system, we ususlly usee Omron PLC.
Q: How long is the warranty of your machinery?
A: Our warranty is one year.
Q: How long is the delivery time?
A: Usually we need 40-60 days , if ther id inventory , we can finish the modification within one month, but it may take longer if ther are special requiements
.

---
