Metal Lathe Big Turning Manual Lathe Machine Cak6140 Cak6150 Cak6160 Cak6166 Cak6180

US$3,000.00-8,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

CAK6140 CAK6150 CAK6160 CAK6166 CAK6180

Type

Horizontal Lathe

Processing Accessory

Metal

Guide Rail

Horizontal Guide Rail

Tool Holder

4 Way Tool Post

Power Source

Electric

Controlling Mode

Artificial

Automatic Grade

Manual

Setting Mode

Floor-type

Precision

High Precision

Certification

CE, RoHS, ISO 9001

Condition

New

Max.Swing Over Bed

500mm

Swing Over Cross Slide

300mm

Width of Bed

400mm

Spindle Bore

105mm

Motor Power

7.5kw

Spindle Taper

Mt6

Spindle Speed

10-1400rpm

Transport Package

Plywood Case

Specification

3200kgs

Trademark

HOYONG-TRD

Origin

Shandong, China

HS Code

84581900

Production Capacity

10 PCS/Month

Product Description

BIG BORE GAP BED LATHE FEATURES:
1.Widen guideway
2.High quality casting body
3.Hardened and ground bed way coated with Turcite-B
4.Integrated automatic lubrication

MODEL SPECIFICATIONS		CA6140 CA6240 CA6140B CA6240B		CA6150 CA6250 CA6150B CA6250B CA6150C CA6250C			CA6161 CA6261 CA6161B CA6261B CA6161C CA6261C		CA6166 CA6266 CA6166B CA6266B CA6166C CA6266C		CA6180 CA6280 CA6180B CA6280B CA6180C CA6280
Max .Swing over bed		400mm		500mm			610mm		660mm		800mm
Max .Swing over carriage		210mm		300mm			370mm		400mm		540mm
Max .Swing in gap		--	630	--		720	--	830	--	880	--	1020
Effective gap length		--	210	--		210	--	210	--	210	--	210
Max .length of work piece		750/1000/1500/2000/2200/3000
Width of bed		400mm
Section of turning tool		25×25mm
Spindle	Spindle speed	10-1400rpm/16-1400rpm(24steps)
	Hole through spindle	52mm ,(80mm),[105mm]
	Spindle taper	(MT6)(Φ90 1:20)[Φ113:20]
Feed	No. of feed	(64 kinds)(for each)
	Range of metric threads	(1-192mm) (44 kinds)
	Range of inch threads	(1-24tpi) (21kinds)
	Range of module threads	0.25-48 (module 39 kinds)
	Range of diametral pitc threads	1-96DP (37 kinds)
Tailstock	Max. tailstock spindle travel	150mm
	Tailstock spindle diameter	75mm
	Taper of tailstock	(MT5)
Main motor		7.5KW(10HP)
Packing	750/1000/1500/2000 /2200/3000/4000	2440/2650/3150/3650/4030/4800/5680×1140×1750
Weight		G.W. N.W.(kg)
	750mm	2100 1990			2170 2060		2300 2180		2380 2260		2520 2400
	1000mm	2190 2070			2260 2140		2380 2250		2570 2450		2720 2560
	1500mm	2350 2220			2420 2290		2577 2437		2810 2640		2980 2800
	2000mm	2720 2570			2790 2640		2940 2787		3050 2880		3260 3087
	2200mm	2800 2600			2940 2790		3120 2970		3390 3180		3490 3287
	3000mm	3300 3200			3450 3300		3600 3450		3930 3687		4220 3887
	4000mm	3500 3400			3750 3600		3950 3800		4580 4200		4850 4500
