4LZ-4.0Z Combine Harvester, Rice Harvester,Wheat Harvester,Corn Harvester,Rapeseed Harvester,Soybean Harvester
4LZ-4.0Z Combine Harvester can harvest rice,wheat,corn,Rapeseed,Soybean.
Use 2m wide cutting header, big chasiss 500*90*50 rubber track,Big grain tank.can working in muddy field
| Model | 4LZ-4.0Z |
| Type | Longitudinal flow, full-feeding, rubber track, self-propelled |
| Working dimension L×W×H | 4950×2450×2860 mm |
| Weight (empty tank) | 2780kg |
| Min. ground clearance | 275mm |
| Ground clearance (under axle house) | | 280mm |
| Harvesting capacity (as per rice and wheat) | 0.23-0.85ha/hour |
| Feed rate | 4.0kg/second |
| Engine | Model | 4L88 |
| Type | In-line, water cooling, four circles, supercharged, Electric EGR |
| Burning chamber type | Direct-injection |
| Cylinder | Dry type, 4cylinders, Diameter=95mm, work sequence:1-3-4-2 |
| Power | 85HP /2600RPM |
| Piston | Stroke 100mm, Swept volume 2.834L |
| Wast gas exhaust | European II | | | | |
| Mini. fuel oil consumption | ≤220g/kw.h |
| Fuel tank | 90L |
| Rubber track | Specification | 500×90×51 |
| Track gauge | External 1555mm, Interal: 755mm |
| Ground contact length | 1650mm |
| Ground Pressure | ≤0.211(0.194) kgf/cm2 |
| Walking gearbox | Type | Mechanical+HST==>stepless transmission |
| Gear | Main gear: forward+reverse; Auxiliary gear: low, harvesting, high |
| Braking type | wet friction plate |
| Walking speed | Forward | Low gear:0-1.43m/s, Harvesting gear: 0-1.87m/s, High gear: 0-2.65m/s |
| Reverse |
| Reel | Type | Tine bars + Eccentric bar frames |
| Diameter | Φ900mm |
| Bar quantity | 5 |
| Control type | Hydraulic |
| Cutter table | Control type | Hydraulic |
| Cutting width | 2M |
| Diameter of head auger | Φ500mm |
| Coneyor type | Chains |
| Threshing unit | Main drum dimension | Φ555×1800mm |
| Main drum type | longitudinal flow |
| Concave | 2 Steel grids |
| Sieve | Shaking sieve, adjustable |
| Cleaning type | Shaking sieve + blowers + re-threshing |
| Blower type and qty | Centrifugal type; 1 |
| Blower diameter | Φ350mm |
| Grain tank | | Small tank 0.33CBM |
| Grain discharging | Manual sacked |
