| Item | Name | Unit | Data | Remark | |
| 1 | Max bending capacity | mm | Φ115×10t | | |
| 2 | Max bending radius | mm | R500 | Can according to customer's requirement | |
| 3. | Min bending radius | mm | Depend on the pipe diameter | | |
| 4 | Max feeding length | mm | 4000 | Can according to customer's requirement | |
| 5 | Max bending degree | Degree | 190 | | |
| 6 | Control Panel | | PLC+ flat computer | | |
| 7 | Bending unit | unit | 16 | | |
| 9 | Accuracy | feeding | mm | ±0.15 | |
| rotary | Degree | ±0.1 | | ||
| bending | Degree | ±0.1 | | ||
| 10 | Data input | 1. coordinate ( X, Y, Z ) 2. Working value ( Y, B, C ) | | ||
| 11 | Rotary servo motor power | KW | 2 | Japan Mitsubishi | |
| 12 | Feeding servo motor power | Kw | 3.5 | Japan Mitsubishi | |
| 13 | Oil motor power | Kw | 28 | | |
| 14 | Max storage units | group | 2000000 | Can enlarge according to requirement | |
| 15 | Max pressure | MPa | 14 | Adjustable | |
| 16 | Machine weight | Kg | 8000 | | |
| 17 | Machine size | mm | 6120×1460×1400 | | |
| 18 | Working height | kg | 7000 | | |
| 19 | Delivery time | days | 30-45 days | | |
| 20 | Warranty time | month | 14 | ||
