| US$800,000.00 | 2 Sets (MOQ) |
| Specification | ||||
| Workpiece Required | Diameter Range(mm) | 20<dia<80 | ||
| Length(mm) | ≥2000 | |||
| Surface Hardness | ≤HB380(≤HRC42) | |||
| Yield Strength(Mpa) | σb≤450 | |||
| Straightness(mm/m) | ≤3.0 | |||
| Diameter Tolerance | ≤h10 | |||
| Circular Degree | ≤50% of diameter tolerance | |||
| Surface Roughness(Ra) | 3.2μm~6.3μm | |||
| After Straightened | Straightness(mm/m) | ≤0.4 | ||
| Surface Roughness(Ra) | 0.8μm | |||
| Diameter Tolerance | h9 | |||
| Roll quantities(pcs) | 2 | |||
| Roll diameter(mm) | Φ335 | |||
| Feeding speed (m/min) | 2~14 | |||
| Main motor(kw) | 45 kw X 2 | |||
| Lifting Motor (kw) | 3 | |||
| Weight(t) | 18.5 | |||
| Total Capacity(kw) | 100 | |||
| Outline Dimension(m) | 7.1 X 2.8 X 3.0(main machine) | |||
