Sliding Door Operator Auto Gate Electronic Door Operator Es200
US$339.00
10 Pieces
(MOQ)
Basic Info.
Model NO.
ES200
Type
Sliding
Open Style
Sliding
Opening Type
With Remote Control
Special Function
Security
Color
Silver
Certification
ISO9001, RoHS, CE
Position
Commercial
Surface Finishing
Finished
Motor
Dunkermotoren Germany
Power Supply
220V or 110V
Length
2000mm to 6000mm
Model
Es200
Function
Works with Original Dorma Parts
4200mm Standard System Weight
Around 45kg
Transport Package
Carton with Film
Specification
CE
Trademark
Will
Origin
China
HS Code
8537101990
Production Capacity
2000sets Every Month
Packaging & Delivery
Package Size
10.00cm * 20.00cm * 10.00cm
Package Gross Weight
2.000kg
Product Description
Automatic Door Operator Sliding Door Operator with Brush Motor automatic door with Dunker Motor ES200
Feature 1...Function 95% similar as Dorma ES200 Easy and works with original dorma ES200 Easy 2. Brush Motor or Dunker Motor 99.5W, powerful enough to bear 2X160KG gates. 3. Easy install since the Drive system has been installed before leavine the factory 4. Germany Dunkermotor, CE approved Standard Configuration 1. Minidrive Unit 2. Transformer 3. Motor 4. Decoder 5. Basic control module 6. Track 7. Carrier 8. Return Pully 9. Service cover holder 10. End stop 11. Door bracket 12. Belt connection 13. Belt tensioning device
Opetional Parts Motion Sensor Lock latch Battery Beam safety photocell Specification ES200 Easy Weight of gate Single/Bi-part1X200KG/2X120KG Width of gate Single/Bi-part900-6100mm Master Controller32 digital microprocessor Brush motor/Dunker motor99.5W 60VDC 2A IP50 Opening speed300-700mm/s Closeing speed300-650mm/s Max open strength150N Hold Open Time/Lock0-10S/30s Height of the rail8CM Deepth of the rail16CM Power SupplyAC110V-250V 50/60Hz Temp15 C to +70 C Power Consumptionaround 100W Protection degree of ElectronicIP23 Function Programs Off Automatic Permanent Open Partial Exit only -------------------------------------------------------------------------------------------------------------------------------------------- Additional Low noise desigh (<40dB) One million times of tests passed Warranty: 18months Emergency Functions Emergency opening in case of power failure / Fail-safe Obstacle detection with automatic return mechanism Self monitoring light barriers Slow speed search for obstruction Workshop
