Digital Measuring Microscope (STM-2515M)

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.

STM-2515M

Number of Cylinder

Binoculars

Mobility

Desktop

Shape

Cylindrical Shaped Lens

Principle

Optics

X,Y,Z-Axis Accuracy

±(3+L/200)Um

Metal Stage Size

408 X 280mm

Glass Stage Size

306 X 196mm

X,Y-Axis Travel

200 X196mm

Z-Axis Travel

150mm

Dimension(Dxwxh)

530X540X850mm

Net Weight

110kg

Contour

Adjustable 256-Frade LED Illumination

Surface

Adjustable 256-Frade LED Illumination

Coaxial

Adjustable LED Coaxial Illumination

Transport Package

Plywood

Specification

Trademark

SINOWON

Origin

Dongguan

HS Code

90318020

Production Capacity

200

Product Description

Product Features:
* Bright field observation, clear and flare less obverse image, wide field of view.
* Long working distance objectives, up to optical 1000x magnification.
* Aperture diaphragms in the transmitted illumination and reflected illumination system as
standard feature.
*The quick-release system, which is especially useful in long-stroke measurements
* Focus and measure using the fine/coarse movement handle with the large-size grips on both
sides of the column.
* Zero-set switches (X- and Y-axis) are also located near the stage feed handles.
* Available with the Vision Unit for upgrading to a vision measuring system.
Specification:

Microscope Model	STM-2515M
Code #	532-180
X/Y-axis travel	250x150mm
Scale Resolution	0.0001mm
XY Stage Measuring Accuracy at 20ºC.	(2+L/200) μm L: measuring length
Observation Image	Obverse image (Erect Image is available)
Eyepiece Tube	Binocular Eyepiece: WF10/20
Objective Lens	Standard delivery: 5x ,10X, 20X, 50x; Optional: 100x
Contour Illumination	Adjustable LED
Surface Illumination	Adjustable LED
Z Axis Travel Range	Standard focus travel:150mm, 200mm is optional
Z Axis Focusing	Manual focusing (Coarse/fine)
XY Stage Floating Function	Quick release mechanism
Display Unit Function	Zero setting, Direction switching, Data output via RS-232
Power Supply	AC220/50HZ; AC110V/60Hz
Optional Accessories	High-Precision Rotary Table RT4(D:165mm), RT5(262mm)
	Digital Readout DP300
	Quickmeasuring Measuring Software QM2.0
	CCD adapter and CCD camera

Optical Specification:

Name	Objective					Eyepiece WF10/22
Name	N.A.	W.D.(mm)	f(mm)	R(um)	±p(um)	Magnification	Visual Field(mm)
5x	0.15	11.6	40	2.1	16.3	50x	¢4.4
10x	0.3	6.3	20	0.9	3.1	100x	¢2.2
20x	0.4	10.3	10	0.69	1.8	200x	¢1.1
50x	0.8	2	4	0.34	0.4	500x	¢0.44
100x	0.8	1.96	2	0.34	0.2	100x	¢0.22
