1)Advanced CNC wire cutting machine has the characteristics of stable cutting and good cutting smoothness.
2)The cutting accuracy and consistency of the machine tool are good.
3)It is suitable for precision workpiece processing and precision die processing.
| No. | Description | Unit | Specification |
| Model |
| A320C |
| 1 | Max. Cutting Speed | mm²/min | 200 |
| 2 | Wire Electrode Diameter | mm | Φ0.10~Φ0.25 |
| 3 | Machining Precision (Cutting the octagon) | mm | ≤0.010/10mm |
| 4 | Taper/Workpiece Height |
| *3°/100mm |
| 5 | Power Consumption | kw | 3kw |
| 6 | Surface roughness | μm | Single cut Ra<2.0,
**Multiple cut Ra<0.8 |
| 7 | High pressure water tank |
| Multi-stage filter system |
| 8 | Plastic water jet plate; Bronze spout |
| Ruby spinneret |
| 9 | Control method of Z-axis manual, transport wire tube, cooling system |
| Controlled by the program and the NC panel |
| 10 | Repeating position precision of X, Y-axis | μm | ±1.5μm |
| 11 | Guide rail type of U,V-axis |
| Linear guide rail |
| 12 | Speed regulation of transport wire tube |
| Converter |
| 13 | Number of control axes |
| 5 |
| 14 | Power Supply |
| AC380V, 50Hz |
***Our company hold the authority to improve the design&specification of the products without special notification.
