Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
Swingframe 1. If a swingframe is used, it is possible to fit equipment to the side of the assembly. Fit 5-off 220mm trunking brackets to the handle side of the swingframe. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. Example 220mm and 60mm brackets are shown right. 2. Fit 80W x 60H trunking to the brackets fitted in the above step. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. The rear edge of the trunking should align with the rear edge of the brackets. 3. Fit a busbar to the trunking brackets, for DC distribution. Note: The busbar should be mounted as close as possible to the power supply that is supplying it. The length of the busbar is determined by the requirements of the system. This may result in additional trunking brackets being required. When determining the length of busbar required, note the following: a For output field power, each output Versatile Field Termination Assembly (VFTA) and each Field Termination Assembly (FTA) will require five busbar terminations. b PSU to busbar feeds will require three busbar terminations. TrustedTM AN-T80003 TrustedTM System Mechanical Build Issue 1 Feb 07 AN-T80003 3 4. Fit 5-off 60mm trunking brackets to the pivot side of the swingframe. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. 5. Fit 60W x 40H x 1775mm long trunking to the brackets fitted above. Locate the trunking as close to the front of the swingframe as possible. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. This trunking will be used for the power supply chassis incoming feeders. 6. Fit a saddle to the rear end bracket at the required position for the power supply chassis incoming power supply feeders ‘swing point’. 7. Fit a TS35 DIN Rail 1775mm long to the trunking brackets on the handle side of the swingframe. Fixings are M5 x 8 Pan Head Taptite screws with large plain and crinkle washers. 8. Check that the ‘Top Hat’ bracket on the rear of the controller and expander chassis are fitted to the pivot side of the swingframe. 9. Fit saddles to each of the ‘Top Hat’ brackets on the rear of the controller and expander chassis. These are ‘swing points’ to carry I/O cables etc. from each chassis to the back of panel ‘swing points’.ack space.
>>
