Product Description
Product Description
Thermal Break Aluminum Shading Curtain Wall/Reflection Mirror Glass Curtain Wall
Welcome to Shanghai MINYE Decoration Co., Ltd. Our company established in 1998, depends on high-quality products under scientific principles, we rising up to the leading enterprise of aluminum & UPVC window & door for almost 20 years. MINYE started export and global trade 8 years ago, it is 6th year named as gold supplier on ALIBABA global sourcing. Our company own factory of ourselves. We can give you a really good price, good quality, and on time delivery. Big order and OEM is welcome.
OVER VIEW
PRODUCTS SPECIFICATION
DESCRIPTION
| Thermal Break Aluminum Shading Curtain Wall/Reflection Mirror Glass Curtain Wall
|
ITEM
| MY15030408
| OPEN STYLE
| Swing
|
PROFILE
| Thermal Break Aluminum
1.4mm Thickness Profile
| GLASS
| Double Hollowed/
Tempered/Glazed Glass
5mm+9A+5mm
|
PROFILE TREATMENT
| Customized color, Anodized
or Powder coated finish
| HARDWARE
| China:YAER or KINLONG
(Hinge, Handle, Lock and so on)
|
SEALING STRIP
| silicon sealant
| CERTIFICATE
| Send for test and certified if required
|
PRODUCT FEATURE
|
SOUND INSULATION
| 24-29(dB)
| WATER TIGHTNESS
|
200~300 (Pa/m2)
|
HEAT INSULATION
| 3.17~3.59(W/m2·k)
| WIND RESISTANCE
| 7.3—12.8x106(kgf/cm2)
|
PAYMENT AND DELIVERY
|
MOQ
| 1 (Set)
| DELIVERY TIME
| 15~30 (days)
|
PAYMENT TERM
| L/C, T/T, O/A
|
|
|
NOTE
|
Parameters for reference only, please refer to actual test result.
|
SECTION DETAILS
GLASS
Glass, as the most important part of the windows, occupies the largest part of the area, for indoor and outdoor lighting and separate role. We can according to customer's diverse needs for scientific configuration and personalized custom services. Customers can choose from a wealth of glass products to choose, to achieve functional and decorative aspects of individual needs.
Standard normal float glass, tempered safety glass or toughened glass, supper white glass, tint glass, coating glass, art glass, double hollow glass or double glazing, LOW E glass, PVB laminated safety glass, frosted glass, double glazing with grill inside, arched tempered glass, etc.
PACKING AND LOADING
1.Small goods will be packed on steel pallet or plywood box.
2.Profile surface will have plastic film cover, aluminum window and door corner would be protected by paper corner gloves.
3.Packing belt will hold goods fasten on the pallet.
4.Stretch wrap will be used for cover whole steel pallet.
AFTER-SALE SERVICE
6 years warranty for whole product, 10 years warranty for German brand hardware,10 years warranty for Austrian brand glazing and 10 years warranty for U.S.A. silicon. Life time service.
POWDER COATING FINISH COLOR CHART
CERTIFICATES
PART OF OUR FINISHED PROJECTS
1. K.A.K.O Building
2. Yancheng Riel International Community
3. Russia Caspian Sea Villa
4. MIXXO Shopping Mall
5. Taizhou Villa
6. Shanghai Western Garden
SHANGHAI MINYE COMPAMY
MINYE obtain the certificates of ISO9001 and ISO14000 in 2000. Our windows and doors were manufactured according to CE standard, AS standard, etc.
Under the total investment fund of USD5.88 Million, our company covers an area of 15,000 square meters area of office building and workshops. Our company has about 400 employees including 50 technicians. 70% of the management directors have over 10 years' experience in the window and door and curtain wall field.
We have a complete set of advanced production equipment, such as aluminum energy-saving doors and windows production lines from WEGOMA GmbH in Germany, and PVC/aluminum windows domestic production lines from Taiwan. With the perfect CAD management systems, we have reached annual production capacity of 400,000 square meters of middle-top grades aluminum/PVC energy-saving doors and windows 100,000 square meters architectural curtain walls.
Our products are widely spread over Europe, the Middle East, South Africa, America and Asia.
EXTENSIVE PRODUCT LINE
Aluminum doors & windows, Aluminum inward turn-tilt window & doors, Aluminum casement window & door, Aluminum sliding window & door, Aluminum side hung windows, Aluminum sky light windows, Aluminum folding door, Aluminum automatic doors, Aluminum KFC doors, PVC doors & windows, UPVC casement window & door, UPVC sliding window s& doors, UPVC Fixed windows, UPVC Hand-cranking casement windows, UPVC side hung windows, UPVC push up windows, Aluminum clad wood windows and doors, Glass windows and doors, Sun room, Sunroom with Herringbone roof, Sunroom with Spire top, Sunroom with circular top, Shutter window, Fly screen, Glass canopy, Curtain wall system, Heterotypic window, Special typed window & door
MNUFACTURING PROCESS
1. Aluminum profile preparing (Raw profile coating or other treatment).
2. Mitered and cutting process.
3. Reinforcement steel cutting and fixing.
4. Aluminum window frame and sash frame assembling.
5. Glazing.
6. Final assembling and hardware assembling.
7. Cleaning, testing packing and loading.
PROCESS AND QUALITY CONTROL
“qualification is the life of the company; administration is the foundation of quality”
In MINYE, we believe that quality is one of the most important elements to seize the customer's psychology. "Quality is produced, not be inspected", we always put this idea firmly throughout each working process, it is not only for our products, it also for our service. Everyone of our MINYE Company, regardless of his job or position, is responsible earnestly for every product quality and service quality. We can create a better future only in this way!
Contact person:
| Chloe Yu
|
Mobile:
| 86 18702118196
| Office Tel:
| 86 021 57670468
|
Fax:
| 86 021 57670469
| Skype:
| minye_sales03
|
Web:
|
| www.shanghai-my.en.china.cn
|
>>
