New Type Vegetable Animal Cottonseed Soybean Colza Peanut Palm Oil Disc Centrifuge

Product Description

Product Description
Centrifuge Principle The disc centrifuge is a liquid-solid (or liquid-liquid solid) separation by utilizing the principle that the components of different densities (or emulsions) have different densities in the centrifugal force field. Disc separator is a kind of 2/3 phase sedimentation disc centrifuge, which is used to separate hard-to-separate materials
(Including mineral oil, gasoline, diesel, dairy products, vegetable oil, beverage, separation and purification of chemical products etc). Structure and principle:
The bowl rotates at a high speed round the main axis, driven by a motor through hydraulic coupling and screw gear pair. stock liquid flows from the upper feeding pipe into the bowl's bottom and then will be separated through holes of disc seat. by the action of centrifugal force field, heavy liquid flows along the inner wall of discs to the inner wall of the bowl, after up flowing along them, it will be discharged by the heavy liquid pump, the light liquid will be done by the light liquid pump, which flows along the inner wall of discs into centre pipe and then up to high liquid outlet. the larger solid phase particles left will sedimentate on the bowl's wall and then will be discharged, controlled by the sliding bowl, out of the sediment outlet. Feature of products DHY series automatic discharging separator is special equipment for oil and fat refining,it has the traits as high rotating speed,operating stability,completely sesled up of the inlet and outlet system,lower noise and fine separating affection. DHNY is used in juice and herbal filtration etc. liquid solid separation industry.
Product Parameters
Support non-standard customization
Application field
1.) Mineral oil industry: purification of fuel oil and lubricating oil such as ship main engine;disc centrifuge
2.)Dairy Industry: clarification, purification degreasing of fresmilk;disc Separator centrifuge
3.)Vegetable oil industry: purification and clarification of palm oil, degumming, soaping, dehydration and dewaxing of refinedvegetable oil;disc Separator centrifuge
4.)Beverage Products Industry: clarification of beer, fruit juice, beverage, etc., disc Separator centrifuge
5.) Starch Industry: Concentration and grading of starch pulp;disc Separator centrifuge
6.)Industry: purification or clarification in the extraction process of antibiotics and biochemical ,disc Separator centrifuge
7.) Chemical Industry: purification or clarification of chemical raw materials;disc Separator centrifuge
8. )Lanolin industry: extract and purify lanolin from wool washing sewage;disc Separator centrifuge
9.) Latex industry: Purify and concentrate natural rubber emulsion;disc Separator centrifuge


Packing&Shipping

Delivery Time	30days
Payment Term	T/T,30% in advance ,70% beforeshipment(negotiable) L/C
Packaging details	Normal packaging is wooden case. We can also according to the special requirements of customers for packaging
Validity	45days from the date we offered

Company Profile
LIAOYANG WANDA MACHINERY CO.,LTD specializes in R&D, manufacturing, operation, export and related services of various types of industrial centrifuge machines, drying equipment, mixer machines, crushers, granulation machines, packing machines etc. The production base is located in Liaoyang City, Liaoning Province, China. Our mechanical equipment products can be widely used in food, chemical, petrochemical, light industry, heavy industry, printing and dyeing industry, feed industry, fertilizer industry,high-tech industry, etc., has been widely welcomed and praised. Wanda Machinery not only has a group of capable engineers and senior management personnel with more than ten years of work experience, but also has a group of excellent production personnel. They have excellent capabilities in research, design, service, etc. Over the years, they have devoted themselves to researching and summing up in practice. "Pragmatism, innovation, integrity, pursuit of excellence", a deep understanding is a strong guarantee for the quality of customers' products! Looking to the future with a commitment to design innovation and quality products, supported by an outstanding level of customer service. The excellent quality machinery can be easily obtained from us because we maintain the quality and standard of our products from incoming raw materials to the finished products.

We sincerely invite you to be our long term relationship friend , and we always prepared to provide our best services for you and would like you to know below we want to present : 1. Each machine is manufactured by professional experienced staff. 2. 12 months warranty + 100% QC inspection Before Shipment. 3. Overseas services provided. Technicians can be sent to spot for guiding the installation and debugging. Training operators and accomplish the commissioning. 4. Consultant services for whole machine life, 24 hours technical support by email and phone.When warranty date expired, lifetime maintenance service is provided and at buyer's cost.
FAQ
1. What data is required to confirm the model? (1) Materials to be separated (2) Treatment capacity per hour (3) Solid content percentage 2. What certificates do you have? We can provide CE, ISO 9001, etc 3. What is the warranty period of the equipment? Normally 1 year warranty 4. Can we visit your factory? Sure, we sincerely invite you to visit 5. Can we bring our own materials to your factory for experiments? Sure, you are welcome at any time. We will arrange professional engineers and technicians to do experiments and analyze data for you on site. 6. Can it be customized? Sure, our equipment can be customized according to the actual requirements of customers. 7. How long is the construction period? It's about 30 days, but it also needs to be determined according to the specific equipment model, order number, etc., But if you need it urgently, please let us know, we can arrange the factory to rush production. 8. Will you provide installation services? If you need, we can arrange professional technicians and engineers to install and debug on site.

---
