| US$295.00 | 1 Piece (MOQ) |
Product Details: | |
| This 2.45GHz active RFID reader DL9230 is designed for inventory management. With its long read and write range of up to 100m, this active RFID reader is perfectly used in enterprise supply chain management to improve the efficiency of inventory tracking and management. | |
| Important Performance | |
| Working Frequency | ISM 2.4GHz ~ 2.5GHz |
| Identify Direction | Semi-omnidirectional |
| Antenna | 15dBi Built-in antenna |
| Polarization | Vertical Polarization |
| RF Power Range | -30 dBm ~ 0 dBm (set by software) |
| Receiving Sensitivity | -90dBm (set by software) |
| Modulation | GFSK |
| Read Performance | |
| Read Mode | 1) Automatic identifying within effective area (Auto mode) |
| 2) Reading after external trigger (Trigger mode) | |
| 3) Reading under software command (Master-slave mode) | |
| Anti-collision | Read up to 200 pieces of tags simultaneously |
| Read Distance | 0 ~ 100 m adjustable |
| Working Status Indication | Buzzer |
| Communication Performance | |
| Communication Speed | 1000kbps |
| Data Port Interface | |
| Port Available | TCP/IP (RJ45) / USB / RS232 / RS485 / Weigand26 / Weigand34 |
| Electric Parameter | |
| Power Supply | DC+9V ~ +15V, 1A |
| Exterior and Weight | |
| Dimension | 320 mm*200 mm*100 mm |
| Weight | 2.5kg |
| Accessories | 12V/1A adapter, Mounting bracket |
| Working Environment | |
| International Protection | IP65 |
| Working Temperature | -20°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
