20m³ Water Heating Vessel Magnesium Hydroxide Slurry, Water Chemical Reactor Mgoh Size Ta1 Pressure Vessel

Product Description

Vessel Capacity m³: 25.3 Material: TA1+Q345R Design pressure MPa: 2.5 Design temperature ºC: 250 Work pressure MPa: 1.8 Work temperature ºC: 200 Medium: Magnesium hydroxide, water Working life: 10 years Jacket Capacity m³: 2.4 Material: Q345R Design pressure MPa: 0.6 Design temperature ºC: 280 Work pressure MPa: 0.5 Work temperature ºC: 260 Medium: Heat transfer oil Heat exchange area m2: 33.0 Coil tube #1 Capacity m³: 0.5 Material: TA2 Design pressure MPa: 1.0 Design temperature ºC: 250 Work pressure MPa: 0.9 Work temperature ºC: 200 Medium: steam Heat exchange area m2: 35.1
Coil tube #2 Capacity m³: 0.4 Material: TA2 Design pressure MPa: 0.6 Design temperature ºC: 160 Work pressure MPa: 0.5 Work temperature ºC: inlet 50/ outlet 150 Medium: softened water Heat exchange area m2: 29.2 Total weight Kg: 21863 *For confidential reason, the drawing is in low definition. Please contact us for more information.

MODEL	FCHA1000-2000L	FCHA3000-5000L	FCHA6000-8000L	FCHA10000-15000L	FCHA15000-25000L
CAPACITY	1000-2000L	3000-5000L	6000-8000L	10000-1 5000L	15000-25000L
WORK PRESSURE MPa	-0.1-10.0	-0.1-10.0	-0.1-10.0	-0.1-10.0	-0.1 -8.0
WORK TEMPERATURE C°	-15-320	-15-320	-15-320	-15-320	-15-320
rpm	0-320	0-320	0-320	0-320	0-320
DC motor power W	3.0-11.0	11.0-22.0	15-37.0	22.0-55.0	37.0-75.0
Main materials	09MnNiDR/16MnDR (low-temperature steel), 15CrMoR (high-temperature steel), stainless steel S30408/S32168/S31603, S39042, titanium material, duplex steel, shackle material, Hastelloy alloy, zirconium material, Monel, and other materials used for explosive composite plates.
Heating form	Jacket thermal oil, jacket steam, outer half pipe, inner coil pipe; Electric heating/flue gas heating (435ºC).
Mixing form	Disc turbine type, asymmetric turbine type, three blade impeller type, disc inclined blade, four wide blade, propulsion type, impeller type, anchor type, frame type, screw belt type, etc.
Shaft sealing form	Magnetic coupling drive with static sealing, zero leakage, long service life, simple installation, safe and environmentally friendly.
Remarks	Other special requirements, touch screen intelligent control, program control, and connection to DCS systems shall be designed, manufactured, and configured according to user needs.

LUHAO Chemical Machinery Co. Ltd

Pressure Vessel Design Information Collection Table

Vessel

Jacket (Coil)

Work Medium

Name

Components

Density (Kg/m³)

Characteristics

Viscosity (cP)

Flow Velocity(m³/h)

Design pressure (Mpa)

Work pressure (Mpa)

Design temperature(ºC)

Work temperature (ºC)

Wall temperature (ºC)

Diamter (mm)

Length (mm)

Capacity(m³)

Effective capacity (m³)

Corrosion allowance (mm)

Corrosion speed (mm/year)

Recommended Materials

Lowest value of average monthly temperature(ºC)

Site location

Installation condition

Indoor or Outdoor

Catalyst Volume(m³)

Catalyst Density(Kg/m³)

Heat Transfer Area()

Coil Specification

Basic Wind Pressure(Mpa)

Seismic Basic Intensity

Ambient Temperature(ºC)

Site Type

Operating Mode

Insulation Materials

Name

Thickness

Density (Kg/m³)

Seal Requirements

Liquid Level Gauge

Emergency Cut-off

Static Electricity Removal

Anti Eddy Current Requirement for Liquid Outlet

Installation and Mantainance Requirements

Expected Useful Life (years)

Safety accessories

Vessel

Jacket (Coil)

Location

Type

Specification

Quantity

Set pressure(Mpa)

Burst disc

Burst pressure(Mpa)

Safety discharge(kg/h)

Agitator

Type

Impeller Diameter(mm)

Speed(r/min)

Motor

Model

Power(kw)

Explosion Proof Grade

Speed reducer

Piping Table

No.

Dimension

Pressure

Connection Size Standard

Connection Surface Type

Function

a

b

c

d

e

f

g

h

j

k

Other Requirements if any
