Technical Parameter of Receiver
|
Depth of Tracking
| The Depth of Tracking Depends on the Material and Specific Applications
|
Cable
| Single pole application:about 0~2m
|
Locating
| Dual pole application:about 0~0.5m
|
Mode
| Single loop line:Up to 2.5m
|
MIN Current
| About 32mA
|
MAX Current
| About 89mA
|
In Work
| 0~40℃,with max relative humidity of 80%
|
In Storage
| -20~60℃,with max relative humidity of 80%
|
Altitude
| <2000m
|
product size
| 241.5mm*78mm*38.5mm/9.5”*3”*1.5”
|
product weight
| 350g/0.77lb
|
power supply
| 6*1.5V AAA Battery
|
Technical Parameters of Transmitter
|
Output Signal
| 125kHz
|
External Voltage
| DC12~400V AC12~400V(50~60Hz)±2.5%
|
Fuse
| F0.5A 1000V
|
MIN Current
| about 31mA
|
MAX Current
| about 115mA
|
In Work
| 0~40℃,with max relative humidity of 80%
|
In Storage
| -20~60℃,with max relative humidity of 80%
|
Altitude
| <2000m
|
Product Size
| 190mm*89mm*42.5/7.48"*3.5"*1.67"
|
Product Weight
| 420g/0.92lb
|
Power Supply
| 1*9V 6F22 Battery
|
| |
Q:Do you have in stock ? Answer: Yes, we usually hold some quantities in stock, such as 100pcs or 200pcs are ready to ship immediately.
Q:What’s the lead-time ? Answer: Normally it takes 3-5 working days after receiving payment.
Q: How do you deliver the goods ? Answer: We send by sea or by air including DHL/FedEx/TNT/UPS etc.
Q:Can you do private label ? Answer: Yes, of course. OEM is absolutely supported; both on package or devices.
Q: What’s you main payment terms ? Answer: T/T,Paypal ,western union and trade assurance is welcome to us.
