Miniature Digital Accelerometer High Impact Resistance and Temperature Calibration Factory Supply Mems Accelerometer

Product Description

Parameter	Conditions	ACM-I00-2	ACM-I00-8	ACM-I00-40	Unit
Measuring range		±2	±8	±40	g
Bias calibration		<2	<5	<10	mg
Measuring axis	axis	X, Y, Z	X, Y, Z	X, Y, Z
Zero bias stability (yearly)		1.5(<5)	7.5(<25)	22(<75)	mg
Resolution threshold	@Hz	<1	<5	<15	mg
Bias temperature coefficient	-55~100°	0.1	0.5	1.5	mg/ºC
Bandwidth		0~≥400	0~≥400	0~≥400	Hz
Resonance frequency		1.6	6.7	6.7	KHz
Output rate	5Hz, 15Hz, 35Hz, 50Hz can be set (RS485 does not have this function)
Output signal	RS232/RS485/RS422/TTL optional
Reliability	MIL-HDBK-217, Level 2
Impact resistance	20000g, 2ms, 1/2sine
Anti-vibration	10grms,10~1000Hz
Waterproof level	IP67
Cable	Standard 1.5m length, wear-resistant, oil-proof, wide temperature, shielded cable 5*0.2mm2
Weight	180g (excluding packaging box)
Connector	6-pin aviation plug
Capacitive loading	1000

COMPANY INFORMATION
ML is a national high-tech enterprise that has been focusingon using inertial navigationand information fusion technology to solve the accuracy and real-time needs ofvarious types ofmoving objects for navigation information such as position and attitude. Our products coverhigh-tech sensor products from MEMS industrial-grade inertial navigation chips to high-precisioninertial navigation modules, which are mainly used in autopilots ofunmanned systems (includingautopilot/drones/unmanned ships) , satellite tracking,robots, intelligent pursuit, high-speedrail/bridge/dam mapping and other fields.
ML has accumulated strong product R&D and innovation capabilities through years ofaccumulation in chip design, process manufacturing, industry algorithms and calibration capabilitiesin the MEMS inertial industry. At present, the company has obtained several invention patents andsoftware copyrights, covering MEMS inertial navigation chips and modules, and has successfully usedthese patents to realize product transformation.

---
