Vertical Drilling Machine (Z5030A Z5032V Z5035A Z5040A Z5050A)

Product Description

Vertical Drilling Machine

Model: Z5030A Z5035A Z5040A Z5050A
Z5032V with 2steps spindle speed, variable in each step

1. Vertical drilling machine
2. Drilling capacity 30/32/35/40/50mm
3. Worktable can tilt 45degree

Specification	Unit	Z5030A	Z5032V	Z5035A	Z5040A	Z5050A
Max. drilling capacity	mm	30	32	35	40	50
Max. tapping capacity	mm	M18	-	M20	M24	M24
Distance from spindle axis to generating line of column	mm	315	290	330	360	360
Max. distance from spindle nose to worktable surface	mm	520	790	610	600	600
Max. distance from spindle nose to base surface	mm	1080	1300	1150	1215	1205
Max. travel of spindle	mm	135	115	150	180	180
Max. adjustment of worktable and table rest	mm	480	790	540	560	525
Swivel of table and table rest	°	±45°	±45°	±45°	±45°	±45°
Spindle bore taper	Morse	3	3	4	4	4
Spindle speed steps		12steps	2steps, variable in each step	12	12	12
Spindle speed range	rpm	70-2600	Low: 55-350, High 350-2300	12steps, 70-2600	42-2050	42-1865
Spindle feed steps		3	-	3	4	4
Spindle feed range	mm/r	0.1, 0.2, 0.3	-	0.1, 0.2, 0.3	0.07,0.15,0.26,0.4	0.07,0.15,0.26,0.4
Column diameter	mm	125	120	140	160	170
Effective working area of table(LxW)	mm	450x450	420x420	500x550	580x450	580x450
Effective working ares of base(LxW)	mm	690x480	600x450	760x500	820x550	820x550
Dimension of T-slot of table and base	mm	2-14, 2-16	2-12	2-14, 2-16	2-14, 2-16	2-14, 2-16
3-Phase two speed AC motor	kw	1.1/1.5	1.1	1.5/2.2	2.2/2.8	2.2/2.8
3-Phase two speed AC motor speed	rpm	960/1450	1440	960/1450	960/1450	960/1450
3-Phase pump motor	kw	0.09	0.06	0.09	0.09	0.09
Packing size	mm	650x1050x1950	900x590x1980	700x1150x2150	700x1150x2150	700x1150x2150
Net/Gross weight	kg	440/500	310/360	670/730	740/800	800/860

Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

---
