Fanuc System Depth 1500 mm 5-Axis Deep Hole Drilling and Milling Machine with CE

Product Description

ZJR10-1210
Product application
Deep hole drilling machines are mainly used in the industries as following:
Mould industry: water line hole, thimble hole, ejection pin hole, electric hole, and inclined hole, etc.
-Hydraulic machinery industry: valve, distributor and pump,etc..
-Automotive industry: cylinder, fuel supply system and other parts
-Aerospace industry: the propeller, landing gear and other parts.
-Chemical and generator industry: heat exchange parts.
ZJR series CNC deep-hole drilling machine is automatic and multifunctional, majoring in deep-hole drilling and cutting, while milling function is also professional. With the modern industry advanced technology, the performance, accuracy, processing range, operating mode and working efficiency are in the international advanced level.
1.FANUC 0i -MD CNC system: stable performance, convenient operation programming, perfect and punctual after-sales service.
2.FANUC servo motor for six coordinate axis and main axis: good characteristic and perfect low speed performance.
3.With high-precision ball screw bar and rolling linear guide, the operating components make positioning accurately.
4.Remote control device is adopted in cooling system. Depends on the hole size, materials, chips and required precision, adjusting the flow rate and pressure can optimize the cooling result.
5.ZJR series CNC deep-hole drilling machine is mainly used for extremely difficult processes of deep-hole in mold industry. It's spoken highly of its high-efficiency, low-cost, humanized technological process.
Technical Specifications of
ZJR Series Six-Axis CNC Deep-hole Drilling Machine Tool

Items		ZJR13-1613
Processing Capacity	Diameter of the Hole for Gun Drill	2.5~35 mm
	Maximum Depth of the Hole for Gun Drill	1300 mm
Processing Range	(X)Processing Range (from Left to Right) of the Working Table	1600 mm
	(Y) Processing Range of Sliding Table	1300 mm
	(Z) Processing Range of Column	600 mm
	(A)The Rotary Angle of Ram	15, 25The Main Axis Turns upward 15 degrees, and down to 25 degrees
Main Axis	Taper Hole of Main Axis	BT50
	Maximum Speed of Main Axis	8000 rpm
Power	Main Axis Motor	15 kw
	X X Axis Servo Motor	36 N.m
	Y Y Axis Servo Motor	36 N.m
	Z Z Axis Servo Motor	36 N.m
	W W Axis Servo Motor	27 N.m
	A A Axis Servo Motor	36 N.m
	B B Axis Servo Motor	36 N.m
	Total Power	60kw
CNC Index Table	Burdening	8 ton
	(×)Measurement	1200×1200 mm
Cooling System	()Pressure Range of Cooling Liquid	2~15 MPa(Set 2~9 MPa)
	()Flux of Cooling Liquid	6~85 L/min
Measurement & Weight	(×)Floor Area of Machine Tool(Length*Width)	8000×6200 mm
	Maximum Height of Machine Tool	5400 mm
	Wight of Machine Tool	30ton
System	CNC System	FANUC 0i-MF
Milling Function	Milling Range	1900mm

---
