| US$8,000.00-11,000.00 | 1 set (MOQ) |
| Item | 20' | 40' |
| Rated SWL | 25-35T | 32-45T |
| Max. SWL | 40T | 50T |
| Dead Weight | 1.2-2.6T | 1.2-2.6T |
| Item | 20' | 40' |
| Distance between lock centers(length) | ≈ 5853 mm | ≈11985 mm |
| Distance between lock centers(width) | ≈ 2260 mm | ≈2260 mm |
| Overall Length | ≈ 6058 mm | ≈12188 mm |
| Overall Width | ≈ 2610 mm | ≈2610 mm |
| Frame Height | ≈ 636 mm | ≈731 mm |
| Item | 20' | 40' |
| Dia. of pressed wire rope slings | 32 mm | 36 mm |
| Length of pressed wire rope slings | 3.5m per piece (4 pieces for each set) | 8.5m per piece (4 pieces for each set) |
| Steel Frame | Material Q345B | Material Q345B |
