Product Description
Product Description
straw cutter, grass cutting machine, hay cutter, corn stick cutter, wheat cutter, straw hay cutter, rice straw cutter
High efficiency hay cutter also named by Straw chopper, straw chopping machine, straw cutting machine
straw grinder, straw crusher, straw shredder, straw shatter machine, cotton stalk cutting machine,
Usage of the hay cutter
Detailed Product Description
this machine can cutter dry and fresh grass , corn stalk and other agriculture waste with big capacity ,
This chaff cutter machine can cutter dry and fresh grass , corn stalk and other agriculture waste
any needs .
Hay cutter Working principle
1.Hay Cutter by motor as a supporting power. Will power transfer to the spindle, the other end of the main shaft gear through the gear box, universal joint, etc will pass the speed to transfer the power of the pressure, and when to grass materials and processing in pressure between grass pressure was holding and certain speed into cut institutions, the high speed rotating tool cut up by the grass turned out the mouth.
2. Hay cutter is a used for processing forage grass, cut green, dry corn straw, straw and the straw returned silage grass machine.
Function characteristics
Hay cutter is suitable for cutting all kinds of green grass, hay, tobacco, wheat straw, and Various kinds of forage grass or medicine.
Technical Parameter
Big model:
Performance configuration
| Model
|
SL9Z-9
| SL9Z-6
| SL9Z-4
| SL9Z-2.5
|
With motor (kW)
| 15
| 7.5
| 5.5
| 4
|
With diesel engine (hp)
| ≥30
| ≥15
| ≥12
| ≥8
|
Capacity(t/h)
| 3-20
| 2.5-15
| 2-8
| 1-4
|
Finished product material length (mm)
| 12.18.25.35
| 12.18.25.35
| 17.22.34.44
| Three kinves15.35
Four knives11.12.26.54
|
Chain conveyor belt
| yes
| yes
| yes
| no
|
Dimension(mm)
| USE
| 2620*214083390
| 1968*2147*2756
| 1020*1520*2756
| 1150*1230*1695
|
Transport
| 2620*1720*1850
| 1393*800*1585
| 1020*63082350
| 1150*510*1050
|
SMALL MODEL:
Model
| SL-0.4
|
Capacity(kg/h)
| 800
|
Weight(kg)
| 55
|
Dimension (mm)
| 1060*950*530
|
Power(kw)
| 2.2-3
|
Rotary speed(r/min)
| 2800
|
Multifunctional one:
It can be used for hay cutting , and also can be used as grain grinding, two feeding mouth.
It is useful for many farms, for livestock, and other animals.
